6-Port Fast Ethernet Switch with 4 PoE Ports (1 x High-Power PoE), One High-Power
60 W PSE PoE Port, Three IEEE 802.3at/af PSE PoE Ports, PoE Power B
Model 561686-UKEAN 766623996297
49 specifications
- Weight410 g
- ColourBlack
- Basic switching RJ-45 Ethernet ports quantity6
- Cable types supportedCat5e
- MAC address table1000 entries
- Rack mountingNo
Overview
- Weight
- 410 g
- Colour
- Black
- Basic switching RJ-45 Ethernet ports quantity
- 6
- Cable types supported
- Cat5e
- MAC address table
- 1000 entries
- Rack mounting
- No
- Brand
- Intellinet
- Category
- Network Switch
- Model
- 561686-UK
- Part number
- 561686-UK
- EAN / UPC
- 766623996297
- Also known as
- Intellinet 6-Port Fast Ethernet Switch with 4 PoE Ports (1 x High-Power PoE), One High-Power 60 W PSE PoE Port, Three IEEE 802.3at/af PSE PoE Ports, PoE Power B
Specifications
49 specifications in 13 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 6 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x |
| Cable types supported | Cat5e |
| Full duplex | Yes |
| Half duplex | Yes |
| Auto-sensing | Yes |
| Flow control support | Yes |
| MAC address auto-aging supported | Yes |
| MAC address auto-learning supported | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 1000 entries |
| Switching capacity | 1.2 Gbit/s |
| Store-and-forward | Yes |
| Packet forwarding rate (10 Mbps) | 14880 pps |
| Packet forwarding rate (100 Mbps) | 148800 pps |
Design
| Specification | Value |
|---|---|
| Rack mounting | No |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Activity, Link, PoE, Power |
Power
| Specification | Value |
|---|---|
| Power source | AC/PoE |
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| DC input voltage | 44 - 57 V |
| Power protection features | Over voltage, Overload, Short circuit |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Total Power over Ethernet (PoE) budget | 65 W |
Other features
| Specification | Value |
|---|---|
| Warranty period | 3 year(s) |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating relative humidity (H-H) | 5 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 153 mm |
| Depth | 87 mm |
| Height | 29 mm |
| Weight | 410 g |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package type | Box |
| Package width | 140 mm |
| Package depth | 190 mm |
| Package height | 70 mm |
| Package weight | 830 g |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC Class B, CE, RoHS, UKCA, NDAA |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case width | 305 mm |
| Master (outer) case length | 400 mm |
| Master (outer) case height | 380 mm |
| Master (outer) case gross weight | 18.9 kg |
| Products per master (outer) case | 20 pc(s) |
