SilverNet SIL 534C24MP

SIL 534C24MP

Model SIL 534C24MPEAN 5060693982804

100 specifications

Noise0 dB
Type19U
Weight4 kg
ColourBlack
Switch typeManaged
Basic switching RJ-45 Ethernet ports quantity24

See all specifications

Overview

Noise: 0 dB
Type: 19U
Weight: 4 kg
Colour: Black
Switch type: Managed
Basic switching RJ-45 Ethernet ports quantity: 24

Brand: SilverNet
Category: Network Switch
Model: SIL 534C24MP
Part number: SIL 534C24MP
EAN / UPC: 5060693982804
Also known as: SilverNet SIL 534C24MP network switch Managed L2+ Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 19U Black

Specifications

100 specifications in 18 groups

Management features

Specification	Value
Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
Web-based management	Yes
ARP inspection	Yes
Traffic classification	Yes
Traffic shaping	Yes
System event log	Yes

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Fast Ethernet (copper) ports quantity	24
Gigabit Ethernet (copper) ports quantity	24
Combo SFP ports quantity	4
SFP module slots quantity	4
Fiber optic connector	LC, SFP
Power connector	AC-in jack

Network

Specification	Value
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support	No
Copper ethernet cabling technology	10BASE-TX, 100BASE-TX, 1000BASE-TX
Port mirroring	Yes
Full duplex	Yes
Half duplex	Yes
IP routing	Yes
Auto MDI/MDI-X	Yes
Auto-negotiation	Yes
Broadcast storm control	Yes
Flow control support	Yes
Link aggregation	Yes
Rate limiting	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	Multiple VXLAN (MUX VLAN), Port-based VLAN, Tagged VLAN
Number of VLANs	256

Optical fiber

Specification	Value
Fiber ethernet cabling technology	1000Base-X

Data transmission

Specification	Value
MAC address table	8000 entries
Switching capacity	56 Gbit/s
Store-and-forward	Yes
Latency (10-100 Mbps)	7 µs
Latency (1 Gbps)	7 µs
Static route	Yes
Jumbo frames support	Yes
Jumbo frames	10000
Packet buffer memory	4 MB

Security

Specification	Value
DHCP features	DHCP client, DHCP server, DHCPv6 client, DHCPv6 server
Access Control List (ACL)	Yes
IGMP snooping	Yes
Authentication	MAC-based authentication, Port-based authentication
Authentication type	IEEE 802.1x, RADIUS
IP-MAC-Port binding	Yes
Loop protection	Yes
MAC address entries	Blackhole MAC address entries, Static MAC address entries
MAC address filtering	Yes
Password protection	Yes
Queue scheduling algorithms	SP, WRR+SP, Weighted Round Robin (WRR)
SSH/SSL support	Yes
Security algorithms	802.1x RADIUS, HTTPS, SNMPv3, SSH-2, SSL/TLS
Static port security	Yes

Multicast features

Specification	Value
Multicast support	Yes

Design

Specification	Value
Rack mounting	Yes
Stackable	Yes
Form factor	19U
Product colour	Black
Housing material	Aluminium
LED indicators	Alarm, LAN, Link, Power, Ring
International Protection (IP) code	IP30
Electromagnetic compatibility	EN55032 Class A, CISPR 32 FCC Part 15B Class A, EN61000 4 2 (ESD) EN61000 4 3 (RS) EN61000 4 4 (EFT) EN61000 4 5 (Surge) EN61000 4 6 (CS) EN61000 4 8 (PFMF)

Performance

Specification	Value
Firmware upgradeable	Yes
Noise level	0 dB
Fanless	Yes
Mean time between failures (MTBF)	250000 h

Power

Specification	Value
Power source	AC
Redundant power supply (RPS) support	Yes
Number of power supply units	2
AC input voltage	100 - 240 V
Power consumption (max)	24 W
Power protection features	Overload, Reverse polarity

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) type supported	Active PoE
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet (PoE) voltage	48 V
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	720 W

Other features

Specification	Value
Warranty period	3 year(s)

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	5 - 90%

Weight & dimensions

Specification	Value
Width	440 mm
Depth	300 mm
Height	45 mm
Weight	4 kg

Packaging content

Specification	Value
Cables included	AC
Quick start guide	Yes
Rack mount kit	Yes

Packaging data

Specification	Value
Package type	Box
Package width	393 mm
Package depth	495 mm
Package height	80 mm
Package weight	5.08 kg

Certificates

Specification	Value
Certification	IEC/EN 62368-1 IEC 60068-2-27 IEC 60068-2-32 IEC 60068-2-6 RoHS

Logistics data

Specification	Value
UK Trade Tariff code	85176200
