SIL 73416MP

SIL 73416MP

Model SIL 73416MPEAN 5060693981630

100 specifications

Weight1.14 kg
ColourBlack
Switch typeManaged
Basic switching RJ-45 Ethernet ports quantity16
Cable types supportedCat5e, Cat6
Fiber ethernet cabling technology1000BASE-FX

See all specifications

Overview

Weight: 1.14 kg
Colour: Black
Switch type: Managed
Basic switching RJ-45 Ethernet ports quantity: 16
Cable types supported: Cat5e, Cat6
Fiber ethernet cabling technology: 1000BASE-FX

Brand: SilverNet
Category: Network Switch
Model: SIL 73416MP
Part number: SIL 73416MP
EAN / UPC: 5060693981630
Also known as: SilverNet SIL 73416MP network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

Specifications

100 specifications in 17 groups

Management features

Specification	Value
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
Web-based management	Yes
Configuring Location Settings (CLI)	Yes
Traffic classification	Yes
Traffic shaping	Yes
System event log	Yes
User operation log	Yes

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	16
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	16
Installed SFP modules quantity	4
Installed SFP+ modules quantity	0
SFP module slots quantity	4
Fiber ports quantity	2
Fiber optic connector	SFP
Console port	RJ-45

Network

Specification	Value
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	10BASE-TX, 100BASE-TX, 1000BASE-TX
Cable types supported	Cat5e, Cat6
Port mirroring	Yes
Full duplex	Yes
Half duplex	Yes
IP routing	Yes
Policy-based routing	Yes
Auto MDI/MDI-X	Yes
Auto-negotiation	Yes
Broadcast storm control	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Flow control support	Yes
Link aggregation	Yes
Rate limiting	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	IP subnet–based VLAN, Interface-based VLAN, Port-based VLAN, Tagged VLAN, VLAN Identifier ( VLAN ID)
Number of VLANs	4095

Optical fiber

Specification	Value
Fiber ethernet cabling technology	1000BASE-FX

Data transmission

Specification	Value
MAC address table	8000 entries
Switching capacity	56 Gbit/s
Forwarding rate	29.76 Mpps
Store-and-forward	Yes
Latency (10-100 Mbps)	7 µs
Latency (1 Gbps)	7 µs
Static route	Yes
Jumbo frames support	Yes
Jumbo frames	10000
Packet buffer memory	4 MB

Security

Specification	Value
DHCP features	DHCP snooping
Access Control List (ACL)	Yes
IGMP snooping	Yes
IP-MAC-Port binding	Yes
Loop protection	Yes
MAC address filtering	Yes
Password protection	Yes

Multicast features

Specification	Value
Multicast support	Yes

Design

Specification	Value
Rack mounting	No
Stackable	Yes
Product colour	Black
Housing material	Aluminium
Temperature sensor	Yes
Reset button	Yes
LED indicators	Data, LAN, PoE, Power
DIN rail mounting	Yes
International Protection (IP) code	IP40
Wall mountable	Yes

Performance

Specification	Value
Firmware upgradeable	Yes
Minimum system requirements	Web Browser

Power

Specification	Value
Power supply included	No
Redundant power supply (RPS) support	Yes
Number of power supply units	1
DC input voltage	9 - 56 V
Power consumption (typical)	7 W
Power consumption (max)	30 W
Power protection features	Overload, Reverse polarity

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) type supported	Active PoE
Power over Ethernet (PoE) ports quantity	16
Power over Ethernet plus (PoE+) ports quantity	16
Power over Ethernet (PoE) voltage	48 V
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	480 W

Operational conditions

Specification	Value
Operating temperature (T-T)	-40 - 75 °C
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	5 - 90%

Weight & dimensions

Specification	Value
Width	75 mm
Depth	140 mm
Height	160 mm
Weight	1.14 kg

Packaging content

Specification	Value
Cables included	RS-232
Quick start guide	Yes
Manual	Yes
User guide	Yes

Packaging data

Specification	Value
Package type	Box
Package width	205 mm
Package depth	215 mm
Package height	95 mm
Package weight	1.4 kg

Certificates

Specification	Value
Certification	CE FCC 15 A IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8 IEC 60068-2-27 IEC 60068-2-32 IEC 60068-2-6 EN50121-4 UKCA BS EN IEC 62368-1:2020+A11:2020 UKCA BS IEC 62321-1:2013, IEC 62321-3-1:2013 UKCA BS IEC 62321-4:2013+AMD1:2017, IEC 62321-5:2013 UKCA BS IE

Logistics data

Specification	Value
UK Trade Tariff code	85176200
