ELECTRA-U04-1GB-60W network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE)
Model ELECTRA-U04-1GB-60WEAN 5715063507728
40 specifications
- Weight630 g
- Switch typeUnmanaged
- Basic switching RJ-45 Ethernet ports quantity4
- Networking standardsIEEE 802.3
- MAC address table2000 entries
- Rack mountingNo
Overview
- Weight
- 630 g
- Switch type
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity
- 4
- Networking standards
- IEEE 802.3
- MAC address table
- 2000 entries
- Rack mounting
- No
- Brand
- Ernitec
- Category
- Network Switch
- Model
- ELECTRA-U04-1GB-60W
- Part number
- ELECTRA-U04-1GB-60W
- EAN / UPC
- 5715063507728
- Also known as
- Ernitec ELECTRA-U04-1GB-60W network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE)
Specifications
40 specifications in 13 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Unmanaged |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 4 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Combo SFP ports quantity | 1 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3 |
| Full duplex | Yes |
| Half duplex | Yes |
| Auto MDI/MDI-X | Yes |
| Flow control support | Yes |
| VLAN support | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 2000 entries |
| Switching capacity | 12 Gbit/s |
| Transmission method | Store-And-Forward |
| Packet forwarding | Yes |
Design
| Specification | Value |
|---|---|
| Rack mounting | No |
| Housing material | Metal |
| LED indicators | Power |
| Number of fans | 0 fan(s) |
Performance
| Specification | Value |
|---|---|
| Plug and Play | Yes |
| Fanless | Yes |
Power
| Specification | Value |
|---|---|
| Input voltage | 100-240 V |
| Power consumption (max) | 3.7 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) type supported | PoE+ |
| Power over Ethernet (PoE) ports quantity | 4 |
| Power over Ethernet (PoE) power per port | 15 W |
| Total Power over Ethernet (PoE) budget | 60 W |
Other features
| Specification | Value |
|---|---|
| Cable length | 250 m |
| Packaging content | switch 1pcs, power cord 1pcs, instruction manual 1pcs,certificate of qualification 1pcs |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 245 mm |
| Depth | 190 mm |
| Height | 60 mm |
| Weight | 630 g |
Packaging content
| Specification | Value |
|---|---|
| Cables included | Power |
| Manual | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 245 mm |
| Package depth | 190 mm |
| Package height | 60 mm |
| Package weight | 930 g |
