Product comparison · 2 network switches

Ernitec ELECTRA-U04-1GB-60W network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) vs Ernitec ELECTRA-U08-1GB-110W network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE)

30specifications compared
15differ
15identical
18known for one product only

Key differences

Basic switching RJ-45 Ethernet ports quantity
- ELECTRA-U04-1GB-60W network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE):4
- ELECTRA-U08-1GB-110W network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE):8
Networking standards
- ELECTRA-U04-1GB-60W network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE):IEEE 802.3
- ELECTRA-U08-1GB-110W network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE):IEEE 802.3u
Switching capacity
- ELECTRA-U04-1GB-60W network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE):12 Gbit/s
- ELECTRA-U08-1GB-110W network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE):20 Gbit/s
Power consumption (max)
- ELECTRA-U04-1GB-60W network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE):3.7 W
- ELECTRA-U08-1GB-110W network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE):6.5 W
Power over Ethernet (PoE) ports quantity
- ELECTRA-U04-1GB-60W network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE):4
- ELECTRA-U08-1GB-110W network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE):8
Power over Ethernet (PoE) power per port
- ELECTRA-U04-1GB-60W network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE):15 W
- ELECTRA-U08-1GB-110W network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE):15.4 W
Total Power over Ethernet (PoE) budget
- ELECTRA-U04-1GB-60W network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE):60 W
- ELECTRA-U08-1GB-110W network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE):110 W
Width
- ELECTRA-U04-1GB-60W network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE):245 mm
- ELECTRA-U08-1GB-110W network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE):315 mm

Side by side

Differences highlightedShow differences only

Comparison of ELECTRA-U04-1GB-60W, ELECTRA-U08-1GB-110W
48 specifications	A Ernitec ELECTRA-U04-1GB-60W network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Model ELECTRA-U04-1GB-60W View product	B Ernitec ELECTRA-U08-1GB-110W network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Model ELECTRA-U08-1GB-110W View product
Management featuresidentical
Switch type	Unmanaged	Unmanaged
Ports & interfaces1 differ
Basic switching RJ-45 Ethernet ports quantityDiffers	4	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)	Gigabit Ethernet (10/100/1000)
Combo SFP ports quantityKnown for one	1	Unknown — not stated by the source
Uplink ports quantityKnown for one	Unknown — not stated by the source	2
Network1 differ
Networking standardsDiffers	IEEE 802.3	IEEE 802.3u
Full duplex	Yes	Yes
Half duplex	Yes	Yes
Auto MDI/MDI-XKnown for one	Yes	Unknown — not stated by the source
Flow control support	Yes	Yes
VLAN support	Yes	Yes
Data transmission1 differ
MAC address table	2000 entries	2000 entries
Switching capacityDiffers	12 Gbit/s	20 Gbit/s
Transmission methodKnown for one	Store-And-Forward	Unknown — not stated by the source
Packet forwardingKnown for one	Yes	Unknown — not stated by the source
Forwarding rateKnown for one	Unknown — not stated by the source	14.88 Mpps
Store-and-forwardKnown for one	Unknown — not stated by the source	Yes
Designidentical
Rack mountingKnown for one	No	Unknown — not stated by the source
Housing material	Metal	Metal
LED indicators	Power	Power
Number of fans	0 fan(s)	0 fan(s)
Performanceidentical
Plug and PlayKnown for one	Yes	Unknown — not stated by the source
Fanless	Yes	Yes
Power1 differ
Input voltageKnown for one	100-240 V	Unknown — not stated by the source
Power consumption (max)Differs	3.7 W	6.5 W
AC input frequencyKnown for one	Unknown — not stated by the source	50/60 Hz
Surge protectionKnown for one	Unknown — not stated by the source	Yes
Surge protection voltageKnown for one	Unknown — not stated by the source	4 kV
Power over Ethernet (PoE)3 differ
Power over Ethernet (PoE)	Yes	Yes
Power over Ethernet (PoE) type supported	PoE+	PoE+
Power over Ethernet (PoE) ports quantityDiffers	4	8
Power over Ethernet (PoE) power per portDiffers	15 W	15.4 W
Total Power over Ethernet (PoE) budgetDiffers	60 W	110 W
Power over Ethernet plus (PoE+) ports quantityKnown for one	Unknown — not stated by the source	8
Other featuresidentical
Cable lengthKnown for one	250 m	Unknown — not stated by the source
Packaging contentKnown for one	switch 1pcs, power cord 1pcs, instruction manual 1pcs,certificate of qualification 1pcs	Unknown — not stated by the source
MountingKnown for one	Unknown — not stated by the source	Desktop
Operational conditionsidentical
Operating temperature (T-T)	0 - 40 °C	0 - 40 °C
Weight & dimensions4 differ
WidthDiffers	245 mm	315 mm
DepthDiffers	190 mm	215 mm
HeightDiffers	60 mm	85 mm
WeightDiffers	630 g	880 g
Packaging contentidentical
Cables included	Power	Power
ManualKnown for one	Yes	Unknown — not stated by the source
Packaging data4 differ
Package widthDiffers	245 mm	315 mm
Package depthDiffers	190 mm	215 mm
Package heightDiffers	60 mm	85 mm
Package weightDiffers	930 g	1.38 kg

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
