Zyxel ATP200 hardware firewall Desktop 2 Gbit/s: Full Specifications

Overview

Connectivity: Wired
Type: Desktop
Weight: 1.4 kg
Firewall throughput: 2 Gbit/s
Heat dissipation: 45.38 BTU/h
Active TCP connections (max): 600000

Brand: Zyxel
Category: Hardware Firewall
Model: ATP200
Part numbers: ATP200-EU0102F, ATP200
EAN / UPC: 3540260177465, 4718937599240, 760559124137
Also known as: Zyxel ATP200 hardware firewall Desktop 2 Gbit/s

Specifications

43 specifications in 15 groups

Data transmission

Specification	Value
Firewall throughput	2 Gbit/s
VPN throughput	0.5 Gbit/s
IPSec VPN throughput	40 Gbit/s
SSL performance	10 transactions/sec
UTM throughput (fast/full scan)	450/450 Gbit/s
Maximum connections (SPI)	2000
HTTPS encryption	Yes

Performance

Specification	Value
Heat dissipation	45.38 BTU/h
Mean time between failures (MTBF)	529688.2 h

Network

Specification	Value
Active TCP connections (max)	600000
Number of VLANs	16

Security

Specification	Value
Stateful Packet Inspection (SPI)	Yes
Content filtering	1

Management features

Specification	Value
LED indicators	Yes
On/off switch	Yes

Ports & interfaces

Specification	Value
Connectivity technology	Wired
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Ethernet LAN (RJ-45) ports	4
Ethernet LAN data rates	10,100,1000 Mbit/s
Number of console ports	1
Ethernet DMZ ports quantity	1
SFP module slots quantity	1
WAN connection	Ethernet (RJ-45)

Design

Specification	Value
Rack mounting	Yes
Form factor	Desktop
Built-in fan	Yes

Power

Specification	Value
Input current	2.5 A
Power consumption (typical)	13.3 W

Certificates

Specification	Value
Certification	FCC Part 15 (Class B), CE EMC (Class B), C-Tick (Class B), BSMI, LVD (EN60950-1), BSMI

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-30 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	10 - 90%

Weight & dimensions

Specification	Value
Dimensions (WxDxH)	272 x 187 x 36 mm
Weight	1.4 kg

Packaging data

Specification	Value
Package width	427 mm
Package height	73 mm
Package depth	247 mm
Package weight	2.42 kg

Packaging content

Specification	Value
Rack mount kit	Yes

Logistics data

Specification	Value
Harmonized System (HS) code	85176990

Other features

Specification	Value
Firewall throughput	2000 Mbit/s
VPN throughput	500 Mbit/s
