Zyxel USG FLEX 50: Full Specifications

Overview

Connectivity: Wired
Weight: 880 g
Firewall throughput: 0.35 Gbit/s
Built-in processor: No
DDoS protection: Yes
Management protocols: SNMP v1, v2c, v3

Brand: Zyxel
Category: Hardware Firewall
Model: USG FLEX 50
Part number: USGFLEX50-EU0101F
EAN / UPC: 4718937626380
Also known as: Zyxel USG FLEX 50 hardware firewall 0.35 Gbit/s

Specifications

47 specifications in 15 groups

Data transmission

Specification	Value
Firewall throughput	0.35 Gbit/s
VPN throughput	0.09 Gbit/s
Maximum firewall connections	20000

Performance

Specification	Value
Built-in processor	No
Heat dissipation	40.92 BTU/h
Concurrent users	15 user(s)
Syslog	Yes
Mean time between failures (MTBF)	655130 h

Network

Specification	Value
Wi-Fi	No
Concurrent SSL/VPN connections (default)	5
Concurrent SSL/VPN connections (maximum)	15
VPN tunnels quantity	10
Static route	Yes

Security

Specification	Value
Security algorithms	3DES, 256-bit AES, DES, HTTPS, IPSec, MD5, SHA-1, SHA-2
DDoS protection	Yes
Firewall security	Yes

Protocols

Specification	Value
Management protocols	SNMP v1, v2c, v3

Management features

Specification	Value
LED indicators	Yes
URL filtering	Yes
Web-based management	Yes

Ports & interfaces

Specification	Value
Connectivity technology	Wired
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Ethernet LAN data rates	10,100,1000 Mbit/s
Number of console ports	1
DC-in jack	Yes
WAN connection	Ethernet (RJ-45)

Design

Specification	Value
Built-in fan	No

Power

Specification	Value
Input current	2.0 A
DC input voltage	12 V
Power consumption (max)	12 W

Certificates

Specification	Value
Certification	FCC Part 15 (Class B), IC, CE EMC (Class B), RCM, BSMI

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-30 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	10 - 90%

Weight & dimensions

Specification	Value
Width	216 mm
Depth	143 mm
Height	33 mm
Weight	880 g

Packaging data

Specification	Value
Package width	276 mm
Package height	185 mm
Package depth	98 mm
Package weight	1.41 kg

Packaging content

Specification	Value
Cables included	LAN (RJ-45)

Other features

Specification	Value
Firewall throughput	350 Mbit/s
VPN throughput	90 Mbit/s
