NETGEAR UTM25S VDSL/ADSL2+

UTM25S VDSL/ADSL2+

Model UTM25S VDSL/ADSL2+Part no. UTM25EWDA-100EUSEAN 606449095647

45 specifications

Memory1024 MB
Speed1 Gbit/s
ConnectivityWired
Weight2.56 kg
Wi-FiNo
Firewall securitySPI

See all specifications

Overview

Memory: 1024 MB
Speed: 1 Gbit/s
Connectivity: Wired
Weight: 2.56 kg
Wi-Fi: No
Firewall security: SPI

Brand: NETGEAR
Category: Hardware Firewall
Model: UTM25S VDSL/ADSL2+
Part number: UTM25EWDA-100EUS
EAN / UPC: 606449095647, 606449095654
Also known as: NETGEAR UTM25S VDSL/ADSL2+ hardware firewall 0.98 Gbit/s

Specifications

45 specifications in 16 groups

Data transmission

Specification	Value
Maximum data transfer rate	1 Gbit/s
Firewall throughput	0.98 Gbit/s
VPN throughput	0.09 Gbit/s
IPS/IDS throughput	240 Mbit/s
Mobile VPN IPSec	25
Mobile VPN SSL	14

Performance

Specification	Value
Internal memory	1024 MB
Concurrent connections	40000
Syslog	Yes

Network

Specification	Value
Wi-Fi	No
Networking standards	IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
DHCP server	Yes
Number of VLANs	255
Port forwarding	Yes
Quality of Service (QoS) support	Yes
ADSL standards	VDSL/ADSL2+

Security

Specification	Value
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, 802.1x RADIUS, DES, MD5, SHA-1, SSL/TLS
Firewall security	SPI
Content filtering	Yes
VPN support	SSL, IPSec

Protocols

Specification	Value
Management protocols	HTTP/HTTPS, SNMP v2c
Routing protocols	RIP-1, RIP-2
Supported network protocols	HTTP, HTTPS, FTP, SMTP, IMAP, POP3

Management features

Specification	Value
LED indicators	Yes
Web-based management	Yes

Ports & interfaces

Specification	Value
Connectivity technology	Wired
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	6
Ethernet DMZ ports quantity	1
WAN connection	Ethernet (RJ-45)

Storage

Specification	Value
Flash memory	2048 MB

Design

Specification	Value
Built-in display	No

Power

Specification	Value
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Input current	1 A

Certificates

Specification	Value
Certification	FCC, CE, VCCI, C-Tick, CE/LVD, cUL, RoHS

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	-20 - 70 °C

Weight & dimensions

Specification	Value
Dimensions (WxDxH)	330 x 286 x 43 mm
Weight	2.56 kg

Packaging content

Specification	Value
Cables included	AC

Logistics data

Specification	Value
Harmonized System (HS) code	85176990

Other features

Specification	Value
Firewall throughput	980 Mbit/s
Maximum data transfer rate	1000 Mbit/s
VPN throughput	90 Mbit/s
