FCS-7111 video servers/encoder
720 x 480 pixels 30 fps
Model FCS-7111EAN 4015867157992
34 specifications
- Memory128 MB
- Maximum video resolution720 x 480 pixels
- Built-in processorTI DM365 SoC
- LED indicatorsLAN, Power, Status
- Copper ethernet cabling technology100BASE-TX, 10BASE-T
- Active tampering alarmYes
Overview
- Memory
- 128 MB
- Maximum video resolution
- 720 x 480 pixels
- Built-in processor
- TI DM365 SoC
- LED indicators
- LAN, Power, Status
- Copper ethernet cabling technology
- 100BASE-TX, 10BASE-T
- Active tampering alarm
- Yes
- Brand
- LevelOne
- Category
- Video Servers/Encoders
- Model
- FCS-7111
- Part number
- FCS-7111
- EAN / UPC
- 4015867157992
- Also known as
- LevelOne FCS-7111 video servers/encoder 720 x 480 pixels 30 fps
Specifications
34 specifications in 12 groups
Video
| Specification | Value |
|---|---|
| Maximum video resolution | 720 x 480 pixels |
| Maximum frame rate | 30 fps |
| MPEG-4 frame rate | 30 fps |
| Motion JPEG frame rate | 30 fps |
| NTSC resolutions | 720 x 480 pixels |
| PAL resolutions | 720 x 576 pixels |
| Video compression formats | M-JPEG, MPEG4 |
Performance
| Specification | Value |
|---|---|
| Built-in processor | TI DM365 SoC |
| Internal memory | 128 MB |
| Flash memory | 128 MB |
| PTZ control | Yes |
| Minimum system requirements | Mozilla Firefox, Internet Explorer 6.x or above Cell Phone: 3GPP Player Real Player: 10.5 or above Quick Time: 6.5 or above |
| Compatible operating systems | Microsoft Windows 2000/XP/Vista |
Design
| Specification | Value |
|---|---|
| LED indicators | LAN, Power, Status |
Network
| Specification | Value |
|---|---|
| Copper ethernet cabling technology | 100BASE-TX, 10BASE-T |
| Power over Ethernet (PoE) | Yes |
| Supported network protocols | IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/ RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1x |
| Wi-Fi | No |
Security
| Specification | Value |
|---|---|
| Active tampering alarm | Yes |
| IP address filtering | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Line-in | Yes |
| Line-out | Yes |
| BNC input ports | 1 |
| DC-in jack | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| I/O terminal ports | 1 |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 5 W |
| Power requirements | 12V DC / 24V AC |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 78.35 x 130 x 33.85 mm |
Packaging content
| Specification | Value |
|---|---|
| Bundled software | LevelOne 64-Channel Monitoring |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 55 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Technical details
| Specification | Value |
|---|---|
| Filtering description | IP-address |
Antenna
| Specification | Value |
|---|---|
| Antenna connector type | BNC |
