TesiraLUX IDH-1
Model TesiraLUX IDH-1Part no. 920-00426-00002EAN 814367024193
26 specifications
- Weight1.8 kg
- ColourBlack
- Maximum video resolution3840 x 2160 pixels
- HDMI input ports quantity1
- Width216 mm
- Operating temperature (T-T)0 - 40 °C
Overview
- Weight
- 1.8 kg
- Colour
- Black
- Maximum video resolution
- 3840 x 2160 pixels
- HDMI input ports quantity
- 1
- Width
- 216 mm
- Operating temperature (T-T)
- 0 - 40 °C
- Brand
- Biamp
- Category
- Video Servers/Encoders
- Model
- TesiraLUX IDH-1
- Part number
- 920-00426-00002
- EAN / UPC
- 814367024193
- Also known as
- Biamp Tesira TesiraLUX IDH-1
Specifications
26 specifications in 9 groups
Video
| Specification | Value |
|---|---|
| Maximum video resolution | 3840 x 2160 pixels |
| Maximum frame rate | 60 fps |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI input ports quantity | 1 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.2 |
| Audio connector type | Terminal |
| BNC input ports | 0 |
| Ethernet LAN (RJ-45) ports | 2 |
| Fiber optic connector | SFP+ |
| Fiber ports quantity | 1 |
| RS-232 ports | 1 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 216 mm |
| Depth | 264 mm |
| Height | 44 mm |
| Weight | 1.8 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 304.8 mm |
| Package depth | 457.2 mm |
| Package height | 127 mm |
| Package weight | 2.77 kg |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95% |
Sustainability
| Specification | Value |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS, Trade Agreements Act (TAA) |
| Sustainability compliance | Yes |
Other features
| Specification | Value |
|---|---|
| Country of origin | United States |
Logistics data
| Specification | Value |
|---|---|
| Export Control Classification Number (ECCN) | 5A992 |
