Pro Series Network Video Server
Model Pro Series Network Video ServerPart no. 550000EAN 766623550000
26 specifications
- Memory16 MB
- Weight230 g
- Maximum video resolution768 x 576 pixels
- LED indicatorsYes
- Copper ethernet cabling technology100BASE-TX, 10BASE-T
- BNC input ports1
Overview
- Memory
- 16 MB
- Weight
- 230 g
- Maximum video resolution
- 768 x 576 pixels
- LED indicators
- Yes
- Copper ethernet cabling technology
- 100BASE-TX, 10BASE-T
- BNC input ports
- 1
- Brand
- Intellinet
- Category
- Video Servers/Encoders
- Model
- Pro Series Network Video Server
- Part number
- 550000
- EAN / UPC
- 766623550000
- Also known as
- Intellinet Pro Series Network Video Server video servers/encoder 768 x 576 pixels 30 fps
Specifications
26 specifications in 9 groups
Video
| Specification | Value |
|---|---|
| Maximum video resolution | 768 x 576 pixels |
| Maximum frame rate | 30 fps |
| NTSC resolutions | 640 x 480, 320 x 240, 160 x 120 |
| PAL resolutions | 768 x 576, 384 x 288, 192 x 144 |
Performance
| Specification | Value |
|---|---|
| Internal memory | 16 MB |
| Flash memory | 4 MB |
| Compression levels | 10:1 |
| PTZ control | No |
| Minimum RAM | 32 MB |
| Minimum processor | Pentium II, 266 MHz |
| Minimum system requirements | VGA card resolution: 800 x 600 Internet Explorer 5.0 NetScape 6.0 |
| Compatible operating systems | Windows 98/98SE/2000/Me/XP |
Design
| Specification | Value |
|---|---|
| LED indicators | Yes |
Network
| Specification | Value |
|---|---|
| Copper ethernet cabling technology | 100BASE-TX, 10BASE-T |
| Supported network protocols | TCP/IP, ARP, RARP, ICMP, DHCP, FTP, SMTP, PPP |
Security
| Specification | Value |
|---|---|
| Password protection type | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| BNC input ports | 1 |
| RS-485 ports | 1 |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 7.5 W |
| Power requirements | 110 - 220V AC |
| Power consumption | 1500 mA |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 85 x 125 x 44.5 mm |
| Weight | 230 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 50 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating relative humidity (H-H) | 30 - 80% |
