SB-520 video servers/encoder
1920 x 1080 pixels 60 fps
Model SB-520
28 specifications
- Maximum video resolution1920 x 1080 pixels
- Card reader integratedYes
- Browser supportedChrome, IE, Firefox
- HDMI input ports quantity2
- Input voltage12 V
- Width179.2 mm
Overview
- Maximum video resolution
- 1920 x 1080 pixels
- Card reader integrated
- Yes
- Browser supported
- Chrome, IE, Firefox
- HDMI input ports quantity
- 2
- Input voltage
- 12 V
- Width
- 179.2 mm
- Brand
- AVer
- Category
- Video Servers/Encoders
- Model
- SB-520
- Part number
- SB-520
- Also known as
- AVer SB-520 video servers/encoder 1920 x 1080 pixels 60 fps
Specifications
28 specifications in 9 groups
Video
| Specification | Value |
|---|---|
| Maximum video resolution | 1920 x 1080 pixels |
| Maximum frame rate | 60 fps |
| Video compression formats | H.264, MOV, MP4 |
Performance
| Specification | Value |
|---|---|
| Card reader integrated | Yes |
| Compatible memory cards | SD, SDHC, SDXC |
| Web-based management | Yes |
Network
| Specification | Value |
|---|---|
| Browser supported | Chrome, IE, Firefox |
| Power over Ethernet (PoE) | Yes |
| Supported network protocols | TCP, UDP, RTMP, RTP, RTSP, RTMPS, HLS |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI input ports quantity | 2 |
| HDMI version | 1.4b |
| Remote (IR) output | 2 |
| Line-in | Yes |
| BNC input ports | 0 |
| DC-in jack | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| Microphone in | Yes |
| RS-485 ports | 1 |
Power
| Specification | Value |
|---|---|
| Input voltage | 12 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 179.2 mm |
| Depth | 210.5 mm |
| Height | 39.8 mm |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Sustainability
| Specification | Value |
|---|---|
| Compliance certificates | CE, RoHS |
| Sustainability compliance | Yes |
