TP-Link JetStream 28-Port Gigabit SFP L2 Managed Network Switch

Model T2600G-28SQPart no. T2600G-28SQ V1EAN 6935364099954

80 specifications

Type1U
ColourBlack
Switch typeManaged
Basic switching RJ-45 Ethernet ports quantity4
10G supportNo
Fiber ethernet cabling technology10GBASE-X, 1000BASE-X

See all specifications

Overview

Type: 1U
Colour: Black
Switch type: Managed
Basic switching RJ-45 Ethernet ports quantity: 4
10G support: No
Fiber ethernet cabling technology: 10GBASE-X, 1000BASE-X

Brand: TP-Link
Category: Network Switch
Model: T2600G-28SQ
Part numbers: T2600G-28SQ V1, T2600G-28SQ
EAN / UPC: 6935364099954, 6935364099961, 845973099954
Also known as: TP-Link JetStream 28-Port Gigabit SFP L2 Managed Network Switch

Specifications

80 specifications in 17 groups

Management features

Specification	Value
Switch type	Managed
Switch layer	L2/L3
Quality of Service (QoS) support	Yes
Web-based management	Yes
ARP inspection	Yes
System event log	Yes

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
SFP module slots quantity	24
SFP+ module slots quantity	4
Fiber optic connector	SFP, SFP+
Console port	RJ-45

Network

Specification	Value
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support	No
Copper ethernet cabling technology	10BASE-T, 100BASE-TX
Port mirroring	Yes
Broadcast storm control	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Flow control support	Yes
Link aggregation	Yes
Rate limiting	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	MAC address-based VLAN, Private VLAN, Protocol-based VLAN, VLAN Identifier ( VLAN ID), Voice VLAN
Number of VLANs	4000

Optical fiber

Specification	Value
Fiber ethernet cabling technology	10GBASE-X, 1000BASE-X

Data transmission

Specification	Value
MAC address table	16000 entries
Switching capacity	128 Gbit/s
Forwarding rate	95.2 Mpps
Number of queues	8
Jumbo frames support	Yes
Jumbo frames	9216
Path MTU discovery	Yes
Packet buffer memory	16 MB

Security

Specification	Value
DHCP features	DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 relay, DHCPv6 snooping
Access Control List (ACL)	Yes
IGMP snooping	Yes
BPDU filtering/protection	Yes
DoS attack prevention	Yes
IP-MAC-Port binding	Yes
Loop protection	Yes
Password protection	Yes
Queue scheduling algorithms	WRR+SP, Weighted Round Robin (WRR)
SSH/SSL support	Yes
Security algorithms	SNMP, SNMPv3, SSH, SSH-2, SSL/TLS

Multicast features

Specification	Value
Multicast support	Yes

Protocols

Specification	Value
GARP VLAN Registration Protocol (GVRP)	Yes

Design

Specification	Value
Rack mounting	Yes
Form factor	1U
Product colour	Black
Number of fans	2 fan(s)

Performance

Specification	Value
Compatible operating systems	Microsoft Windows 98SE, NT, 2000, XP, Vista, Windows 7/8, MAC OS, NetWare, UNIX, Linux
Firmware upgradeable	Yes
sFlow	Yes

Power

Specification	Value
Power source	AC
Power supply included	Yes
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	29.67 W

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	No

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Heat dissipation	101.23 BTU/h

Weight & dimensions

Specification	Value
Width	440 mm
Depth	220 mm
Height	44 mm

Packaging content

Specification	Value
Cables included	AC
Rack mount kit	Yes
User guide	Yes

Packaging data

Specification	Value
Resource CD	Yes
Rubber feet	Yes
Package width	528 mm
Package depth	336 mm
Package height	100 mm
Package weight	4.2 kg

Certificates

Specification	Value
Certification	CE, FCC, RoHS
