D-Link DGS-3130-54PS Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black, Grey

DGS-3130-54PS Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black, Grey

Model DGS-3130-54PSPart no. DGS313054PSEAN 790069435324

71 specifications

Noise54.2 dB
Weight5.14 kg
ColourBlack, Grey
Switch typeManaged
Basic switching RJ-45 Ethernet ports quantity48
10G supportYes

See all specifications

Overview

Noise: 54.2 dB
Weight: 5.14 kg
Colour: Black, Grey
Switch type: Managed
Basic switching RJ-45 Ethernet ports quantity: 48
10G support: Yes

Brand: D-Link
Category: Network Switch
Model: DGS-3130-54PS
Part numbers: DGS313054PS, DGS-3130-54PS/SI, DGS-3130-54PS/B
EAN / UPC: 790069435324, 790069469268
Also known as: D-Link DGS-3130-54PS Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black, Grey

Specifications

71 specifications in 14 groups

Management features

Specification	Value
Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Web-based management	Yes
ARP inspection	Yes
MIB support	RFC 1213; RFC 4188; RFC 1157, 2571-2576; RFC 1907; RFC 1757, 2819; RFC 2021; RFC 1398, 1643, 1650, 2358, 2665; RFC 2674 802.1p 2233, 2863 IF MIB; RFC 2618; RFC 2620; RFC 2925; RFC 2674, 4363; RFC 1065, 1066, 1155, 1156, 2578; RFC 1215; RFC 1212; RFC 1215; RFC 1157, 2571-2576; RFC 4022; RFC 4113; RFC

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
SFP+ module slots quantity	4
Fiber optic connector	SFP+
USB 2.0 ports quantity	1
Power connector	AC-in jack

Network

Specification	Value
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x
10G support	Yes
Copper ethernet cabling technology	10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T
Port mirroring	Yes
Flow control support	Yes
Head-of-line (HOL) blocking	Yes
Link aggregation	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	Private VLAN, Voice VLAN, Tagged VLAN, MAC address-based VLAN, Port-based VLAN
Number of VLANs	4000

Data transmission

Specification	Value
MAC address table	16384 entries
Switching capacity	216 Gbit/s
Forwarding rate	161 Mpps
Jumbo frames support	Yes
Jumbo frames	9000
Packet buffer memory	4 MB

Security

Specification	Value
DHCP features	DHCP server, DHCP snooping, DHCP relay, DHCP client
Access Control List (ACL)	Yes
Access Control List (ACL) rules	2048
IGMP snooping	Yes
Authentication	MAC-based authentication, Port-based authentication, Web-based authentication
BPDU filtering/protection	Yes
DoS attack prevention	Yes
Loop protection	Yes
Queue scheduling algorithms	SP, WRR+SP, Weighted Round Robin (WRR)
Root protection	Yes
SSH/SSL support	Yes
Security algorithms	SNMP, SNMPv3, SSH-2, SSL/TLS

Multicast features

Specification	Value
Multicast support	Yes

Protocols

Specification	Value
Routing protocols	RIP

Design

Specification	Value
Stackable	Yes
Product colour	Black, Grey
LED indicators	Yes
Number of fans	4 fan(s)
Safety	CB, cUL, BSMI, CCC

Performance

Specification	Value
Physical stacking (units)	9
Virtual stacking (units)	32
Noise level	54.2 dB
Mean time between failures (MTBF)	356876 h

Power

Specification	Value
Redundant power supply (RPS) support	Yes
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	487.26 W

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet plus (PoE+) ports quantity	48
Total Power over Ethernet (PoE) budget	370 W

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Heat dissipation	1662.6 BTU/h

Weight & dimensions

Specification	Value
Width	440 mm
Depth	350 mm
Height	44 mm
Weight	5.14 kg

Certificates

Specification	Value
Certification	FCC A, CE A, VCCI A, IC, RCM, BSMI, CCC
