D-Link Data Center 10GbE

D-Link Data Center 10GbE

Model Data Center 10GbEPart no. DXS-3600-32S/SIEAN 790069369285

74 specifications
  • Speed10 Gbit/s
  • Weight9.84 kg
  • ColourBlack
  • Switch typeManaged
  • SFP/SFP+ slots quantity24
  • 10G supportYes
See all specifications

Overview

Speed
10 Gbit/s
Weight
9.84 kg
Colour
Black
Switch type
Managed
SFP/SFP+ slots quantity
24
10G support
Yes
Brand
D-Link
Model
Data Center 10GbE
Part number
DXS-3600-32S/SI
EAN / UPC
790069369285, 790069384783, 7900693847834
Also known as
D-Link Data Center 10GbE Managed L3 Black

Specifications

74 specifications in 16 groups

Management features

Switch typeManaged
Switch layerL3
Quality of Service (QoS) supportYes
Web-based managementYes
MIB supportYes

Ports & interfaces

SFP/SFP+ slots quantity24
SFP+ module slots quantity24
Console portRJ-45
HDMI stacking ports0

Network

Networking standardsIEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3x
10G supportYes
Port mirroringYes
Full duplexYes
IP routingYes
Broadcast storm controlYes
Flow control supportYes
Head-of-line (HOL) blockingYes
Link aggregationYes
Spanning tree protocolYes

Data transmission

MAC address table128000 entries
Supported data transfer rates10 Gbit/s
Switching capacity960 Gbit/s
Number of queues8
Maximum data transfer rate10 Gbit/s
Jumbo frames supportYes
Packet buffer memory9 MB

Security

DHCP featuresDHCP server, DHCP client
Access Control List (ACL)Yes
MAC address filteringYes
SSH/SSL supportYes
Static port securityYes

Multicast features

Multicast supportYes

Protocols

Management protocolsSNMP / RMON

Design

Rack mountingYes
StackableYes
Product colourBlack
LED indicatorsFan fail, Power
SafetyCB, cUL, LVD
Electromagnetic compatibilityEMI/EMC FCC, CE, C-Tick, IC, VCCI

Power

AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (typical)115.3 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Other features

Cabling technology10/100/1000 Base-T

Operational conditions

Operating temperature (T-T)0 - 45 °C
Storage temperature (T-T)40 - 70 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Heat dissipation393.4 BTU/h

Weight & dimensions

Width506 mm
Depth440 mm
Height44 mm
Weight9.84 kg

Packaging data

Package width582 mm
Package depth745 mm
Package height137 mm
Package weight13.3 kg

Technical details

Master (outer) cases per pallet (air)12 pc(s)
Master (outer) cases per pallet (sea)12 pc(s)
Pallet gross length110 cm
Pallet gross weight (air)200.3 kg
Pallet gross weight (sea)200.3 kg
Pallet gross width120 cm
Pallet height (air)115.5 cm
Pallet height (sea)115.5 cm
Products per pallet (air)12 pc(s)
Products per pallet (sea)12 pc(s)
Products per shipping (inner) case1 pc(s)
Shipping (inner) case gross weight15.1 kg
Shipping (inner) case height17 cm
Shipping (inner) case length76.3 cm
Shipping (inner) case net weight11.5 kg
Shipping (inner) case width60 cm

Logistics data

Harmonized System (HS) code85176990
