Product comparison · 2 network switches

D-Link Data Center 10GbE vs HP 7500 48-port Gig-T PoE-ready Module

7specifications compared
6differ
1identical
69known for one product only

Key differences

10G support
- Data Center 10GbE:Yes
- 7500 48-port Gig-T PoE-ready Module:No
Width
- Data Center 10GbE:506 mm
- 7500 48-port Gig-T PoE-ready Module:355 mm
Depth
- Data Center 10GbE:440 mm
- 7500 48-port Gig-T PoE-ready Module:377 mm
Height
- Data Center 10GbE:44 mm
- 7500 48-port Gig-T PoE-ready Module:40 mm
Weight
- Data Center 10GbE:9.84 kg
- 7500 48-port Gig-T PoE-ready Module:3.09 kg

Side by side

Differences highlightedShow differences only

Comparison of Data Center 10GbE, 7500 48-port Gig-T PoE-ready Module
76 specifications	A D-Link Data Center 10GbE View product	B HP 7500 48-port Gig-T PoE-ready Module View product
Management featuresidentical
Switch typeKnown for one	Managed	Unknown — not stated by the source
Switch layerKnown for one	L3	Unknown — not stated by the source
Quality of Service (QoS) supportKnown for one	Yes	Unknown — not stated by the source
Web-based managementKnown for one	Yes	Unknown — not stated by the source
MIB supportKnown for one	Yes	Unknown — not stated by the source
Ports & interfacesidentical
SFP/SFP+ slots quantityKnown for one	24	Unknown — not stated by the source
SFP+ module slots quantityKnown for one	24	Unknown — not stated by the source
Console portKnown for one	RJ-45	Unknown — not stated by the source
HDMI stacking portsKnown for one	0	Unknown — not stated by the source
Basic switching RJ-45 Ethernet ports quantityKnown for one	Unknown — not stated by the source	48
Basic switching RJ-45 Ethernet ports typeKnown for one	Unknown — not stated by the source	Gigabit Ethernet (10/100/1000)
Network2 differ
Networking standardsDiffers	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3x	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
10G supportDiffers	Yes	No
Port mirroringKnown for one	Yes	Unknown — not stated by the source
Full duplexKnown for one	Yes	Unknown — not stated by the source
IP routingKnown for one	Yes	Unknown — not stated by the source
Broadcast storm controlKnown for one	Yes	Unknown — not stated by the source
Flow control supportKnown for one	Yes	Unknown — not stated by the source
Head-of-line (HOL) blockingKnown for one	Yes	Unknown — not stated by the source
Link aggregationKnown for one	Yes	Unknown — not stated by the source
Spanning tree protocolKnown for one	Yes	Unknown — not stated by the source
Data transmissionidentical
MAC address tableKnown for one	128000 entries	Unknown — not stated by the source
Supported data transfer ratesKnown for one	10 Gbit/s	Unknown — not stated by the source
Switching capacityKnown for one	960 Gbit/s	Unknown — not stated by the source
Number of queuesKnown for one	8	Unknown — not stated by the source
Maximum data transfer rateKnown for one	10 Gbit/s	Unknown — not stated by the source
Jumbo frames supportKnown for one	Yes	Unknown — not stated by the source
Packet buffer memoryKnown for one	9 MB	Unknown — not stated by the source
Securityidentical
DHCP featuresKnown for one	DHCP server, DHCP client	Unknown — not stated by the source
Access Control List (ACL)Known for one	Yes	Unknown — not stated by the source
MAC address filteringKnown for one	Yes	Unknown — not stated by the source
SSH/SSL supportKnown for one	Yes	Unknown — not stated by the source
Static port securityKnown for one	Yes	Unknown — not stated by the source
Multicast featuresidentical
Multicast supportKnown for one	Yes	Unknown — not stated by the source
Protocolsidentical
Management protocolsKnown for one	SNMP / RMON	Unknown — not stated by the source
Designidentical
Rack mounting	Yes	Yes
StackableKnown for one	Yes	Unknown — not stated by the source
Product colourKnown for one	Black	Unknown — not stated by the source
LED indicatorsKnown for one	Fan fail, Power	Unknown — not stated by the source
SafetyKnown for one	CB, cUL, LVD	Unknown — not stated by the source
Electromagnetic compatibilityKnown for one	EMI/EMC FCC, CE, C-Tick, IC, VCCI	Unknown — not stated by the source
Poweridentical
AC input voltageKnown for one	100 - 240 V	Unknown — not stated by the source
AC input frequencyKnown for one	50 - 60 Hz	Unknown — not stated by the source
Power consumption (typical)Known for one	115.3 W	Unknown — not stated by the source
Power over Ethernet (PoE)identical
Power over Ethernet (PoE)Known for one	No	Unknown — not stated by the source
Other featuresidentical
Cabling technologyKnown for one	10/100/1000 Base-T	Unknown — not stated by the source
Operational conditionsidentical
Operating temperature (T-T)Known for one	0 - 45 °C	Unknown — not stated by the source
Storage temperature (T-T)Known for one	40 - 70 °C	Unknown — not stated by the source
Operating relative humidity (H-H)Known for one	0 - 95%	Unknown — not stated by the source
Storage relative humidity (H-H)Known for one	0 - 95%	Unknown — not stated by the source
Heat dissipationKnown for one	393.4 BTU/h	Unknown — not stated by the source
Weight & dimensions4 differ
WidthDiffers	506 mm	355 mm
DepthDiffers	440 mm	377 mm
HeightDiffers	44 mm	40 mm
WeightDiffers	9.84 kg	3.09 kg
Packaging dataidentical
Package widthKnown for one	582 mm	Unknown — not stated by the source
Package depthKnown for one	745 mm	Unknown — not stated by the source
Package heightKnown for one	137 mm	Unknown — not stated by the source
Package weightKnown for one	13.3 kg	Unknown — not stated by the source
Technical detailsidentical
Master (outer) cases per pallet (air)Known for one	12 pc(s)	Unknown — not stated by the source
Master (outer) cases per pallet (sea)Known for one	12 pc(s)	Unknown — not stated by the source
Pallet gross lengthKnown for one	110 cm	Unknown — not stated by the source
Pallet gross weight (air)Known for one	200.3 kg	Unknown — not stated by the source
Pallet gross weight (sea)Known for one	200.3 kg	Unknown — not stated by the source
Pallet gross widthKnown for one	120 cm	Unknown — not stated by the source
Pallet height (air)Known for one	115.5 cm	Unknown — not stated by the source
Pallet height (sea)Known for one	115.5 cm	Unknown — not stated by the source
Products per pallet (air)Known for one	12 pc(s)	Unknown — not stated by the source
Products per pallet (sea)Known for one	12 pc(s)	Unknown — not stated by the source
Products per shipping (inner) caseKnown for one	1 pc(s)	Unknown — not stated by the source
Shipping (inner) case gross weightKnown for one	15.1 kg	Unknown — not stated by the source
Shipping (inner) case heightKnown for one	17 cm	Unknown — not stated by the source
Shipping (inner) case lengthKnown for one	76.3 cm	Unknown — not stated by the source
Shipping (inner) case net weightKnown for one	11.5 kg	Unknown — not stated by the source
Shipping (inner) case widthKnown for one	60 cm	Unknown — not stated by the source
Logistics dataidentical
Harmonized System (HS) codeKnown for one	85176990	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
