ZyWall USG-200 Bundle
Model ZyWall USG-200 BundlePart no. 96-996-000092
24 specifications
- Memory256 MB
- ConnectivityWired
- Weight1.2 kg
- Firewall throughput0.15 Gbit/s
- Number of users50 user(s)
- Connectivity LEDsSYS, AUX, CARD
Overview
- Memory
- 256 MB
- Connectivity
- Wired
- Weight
- 1.2 kg
- Firewall throughput
- 0.15 Gbit/s
- Number of users
- 50 user(s)
- Connectivity LEDs
- SYS, AUX, CARD
- Brand
- Zyxel
- Category
- Hardware Firewall
- Model
- ZyWall USG-200 Bundle
- Part number
- 96-996-000092
- Also known as
- Zyxel ZyWall USG-200 Bundle hardware firewall 0.15 Gbit/s
Specifications
24 specifications in 11 groups
Data transmission
| Specification | Value |
|---|---|
| Firewall throughput | 0.15 Gbit/s |
| VPN throughput | 0.075 Gbit/s |
Performance
| Specification | Value |
|---|---|
| Internal memory | 256 MB |
| Concurrent connections | 40000 |
Network
| Specification | Value |
|---|---|
| Number of users | 50 user(s) |
| VPN tunnels quantity | 100 |
Security
| Specification | Value |
|---|---|
| VPN support | AES, 3DES, DES, SHA-1, MD5, IKE, DH 1, 2, 5, NAT, PKI (X.509), CMP, SCEP, L2TP |
Protocols
| Specification | Value |
|---|---|
| Management protocols | HTTPS, HTTP, SSH, TELNET, SNMP v2c (MIB-II), CNM |
Management features
| Specification | Value |
|---|---|
| Connectivity LEDs | SYS, AUX, CARD |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| USB 2.0 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 7 |
| RS-232 ports | 2 |
Storage
| Specification | Value |
|---|---|
| Flash memory | 256 MB |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 242 x 175 x 35.5 mm |
| Weight | 1.2 kg |
Other features
| Specification | Value |
|---|---|
| Power requirements | 100 - 240 VAC, 1.2A, 50/60 Hz |
| Authentication method | SHA-1, MD5, LDAP, RADIUS |
| Firewall throughput | 150 Mbit/s |
| VPN throughput | 75 Mbit/s |
| I/O ports | 1x RS-232 (DB9F), 1x RS-232 (DB9M), 1x CS, 1x PCMCIA |
