USG310 hardware firewall 6 Gbit/s
Model USG310Part no. USG310-EU0102FEAN 4718937578665
26 specifications
- ConnectivityWired
- Weight3.3 kg
- Firewall throughput6 Gbit/s
- Concurrent connections100000
- Number of VPN connections105
- Rack mountingYes
Overview
- Connectivity
- Wired
- Weight
- 3.3 kg
- Firewall throughput
- 6 Gbit/s
- Concurrent connections
- 100000
- Number of VPN connections
- 105
- Rack mounting
- Yes
- Brand
- Zyxel
- Category
- Hardware Firewall
- Model
- USG310
- Part numbers
- USG310-EU0102F, USG310-GB0102F
- EAN / UPC
- 4718937578665, 4718937584864
- Also known as
- Zyxel USG310 hardware firewall 6 Gbit/s
Specifications
26 specifications in 11 groups
Data transmission
| Specification | Value |
|---|---|
| Firewall throughput | 6 Gbit/s |
| VPN throughput | 0.65 Gbit/s |
Performance
| Specification | Value |
|---|---|
| Concurrent connections | 100000 |
| Mean time between failures (MTBF) | 560811.5 h |
Network
| Specification | Value |
|---|---|
| Number of VPN connections | 105 |
| Number of users | 25 user(s) |
| VPN tunnels quantity | 300 |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Gigabit Ethernet (copper) ports quantity | 8 |
| USB 2.0 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 8 |
| Serial ports quantity | 1 |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 1.3 A |
| Power consumption (typical) | 58.5 W |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC, CE EMC, C-Tick, BSMI, LVD (EN60950-1), BSMI |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -30 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 430 x 250 x 44 mm |
| Weight | 3.3 kg |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
Other features
| Specification | Value |
|---|---|
| Firewall throughput | 6000 Mbit/s |
| VPN throughput | 650 Mbit/s |
