Zyxel USG Flex 500: Full Specifications

Overview

Noise: 41.5 dB
Type: 1U
Weight: 1.65 kg
Firewall throughput: 2.3 Gbit/s
Heat dissipation: 82.23 BTU/h
Number of VPN connections: 500

Brand: Zyxel
Category: Hardware Firewall
Model: USG Flex 500
Part numbers: USGFLEX500-GB0101F, USGFLEX500-EU0102F, USGFLEX500-EU0101F
EAN / UPC: 4718937635016, 760559127275, 4718937612062, 4718937612055
Also known as: Zyxel USG Flex 500 hardware firewall 1U 2.3 Gbit/s

Specifications

39 specifications in 15 groups

Data transmission

Specification	Value
Firewall throughput	2.3 Gbit/s
VPN throughput	0.81 Gbit/s

Performance

Specification	Value
Heat dissipation	82.23 BTU/h
Noise level	41.5 dB
Mean time between failures (MTBF)	529688 h

Network

Specification	Value
Number of VPN connections	500
Concurrent SSL/VPN connections (maximum)	150
VPN tunnels quantity	300
Number of VLANs	64

Security

Specification	Value
Security algorithms	IPSEC, SSL/TLS
VPN support	IKEv2, IPSec, SSL, L2TP/IPSec

Management features

Specification	Value
URL filtering	Yes

Ports & interfaces

Specification	Value
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Ethernet LAN (RJ-45) ports	7
Number of console ports	1
SFP module slots quantity	1

Design

Specification	Value
Rack mounting	Yes
Form factor	1U
Built-in fan	Yes

Power

Specification	Value
Input current	4.17 A
Power consumption (max)	24.1 W

Certificates

Specification	Value
Certification	DCC, CE, C-Tick, LVD

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-30 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	10 - 90%

Weight & dimensions

Specification	Value
Width	300 mm
Depth	188 mm
Height	44 mm
Weight	1.65 kg

Packaging data

Specification	Value
Package width	351 mm
Package height	152 mm
Package depth	245 mm
Package weight	2.83 kg

Packaging content

Specification	Value
Rack mount kit	Yes
Bundled software	1 year UTM

Logistics data

Specification	Value
Harmonized System (HS) code	85176990

Other features

Specification	Value
Firewall throughput	2300 Mbit/s
VPN throughput	810 Mbit/s
