USG Flex 100
Model USG Flex 100Part no. USGFLEX100-EU0111FEAN 4718937630950
34 specifications
- Weight850 g
- Firewall throughput0.9 Gbit/s
- Heat dissipation42.65 BTU/h
- Number of VPN connections100
- Security algorithmsIPSEC, SSL/TLS
- URL filteringYes
Overview
- Weight
- 850 g
- Firewall throughput
- 0.9 Gbit/s
- Heat dissipation
- 42.65 BTU/h
- Number of VPN connections
- 100
- Security algorithms
- IPSEC, SSL/TLS
- URL filtering
- Yes
- Brand
- Zyxel
- Category
- Hardware Firewall
- Model
- USG Flex 100
- Part numbers
- USGFLEX100-EU0111F, USGFLEX100-EU0101F, USGFLEX100-EU0102F, USGFLEX100BUN, USGFLEX100-EU0112F
- EAN / UPC
- 4718937630950, 4718937611935, 4718937611942, 760559127244 +2 more
- Also known as
- Zyxel USG Flex 100 hardware firewall 0.9 Gbit/s
Specifications
34 specifications in 14 groups
Data transmission
| Specification | Value |
|---|---|
| Firewall throughput | 0.9 Gbit/s |
| VPN throughput | 0.27 Gbit/s |
Performance
| Specification | Value |
|---|---|
| Heat dissipation | 42.65 BTU/h |
| Mean time between failures (MTBF) | 989810 h |
Network
| Specification | Value |
|---|---|
| Number of VPN connections | 100 |
| Concurrent SSL/VPN connections (maximum) | 30 |
| VPN tunnels quantity | 64 |
| Number of VLANs | 8 |
Security
| Specification | Value |
|---|---|
| Security algorithms | IPSEC, SSL/TLS |
| VPN support | IKEv2, IPSec, SSL, L2TP/IPSec |
Management features
| Specification | Value |
|---|---|
| URL filtering | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 4 |
| Console port | RJ-45 |
| WAN connection | Ethernet (RJ-45) |
Design
| Specification | Value |
|---|---|
| Built-in fan | No |
Power
| Specification | Value |
|---|---|
| Input current | 2 A |
| Power consumption (max) | 12.5 W |
Certificates
| Specification | Value |
|---|---|
| Certification | DCC, CE, C-Tick, LVD |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -30 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 216 mm |
| Depth | 147.3 mm |
| Height | 33 mm |
| Weight | 850 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 284 mm |
| Package height | 190 mm |
| Package depth | 100 mm |
| Package weight | 1.4 kg |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
Other features
| Specification | Value |
|---|---|
| Firewall throughput | 900 Mbit/s |
| VPN throughput | 270 Mbit/s |
