Zyxel USG 310: Full Specifications

Overview

Connectivity: Wired
Weight: 3.3 kg
Firewall throughput: 6 Gbit/s
Concurrent connections: 100000
Number of VPN connections: 105
LED indicators: Yes

Brand: Zyxel
Category: Hardware Firewall
Model: USG 310
Part number: USG310-EU0103F
EAN / UPC: 4718937620470
Also known as: Zyxel USG 310 hardware firewall 6 Gbit/s

Specifications

27 specifications in 12 groups

Data transmission

Specification	Value
Firewall throughput	6 Gbit/s
VPN throughput	0.65 Gbit/s

Performance

Specification	Value
Concurrent connections	100000
Mean time between failures (MTBF)	560811.5 h

Network

Specification	Value
Number of VPN connections	105
Number of users	25 user(s)
VPN tunnels quantity	300

Management features

Specification	Value
LED indicators	Yes

Ports & interfaces

Specification	Value
Connectivity technology	Wired
Gigabit Ethernet (copper) ports quantity	8
Serial ports quantity	1

Design

Specification	Value
Rack mounting	Yes

Power

Specification	Value
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Input current	1.3 A
Power consumption (typical)	58.5 W

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-30 - 70 °C
Operating relative humidity (H-H)	10 - 90%

Weight & dimensions

Specification	Value
Width	430 mm
Depth	250 mm
Height	44 mm
Weight	3.3 kg

Packaging content

Specification	Value
Cables included	AC

Logistics data

Specification	Value
Harmonized System (HS) code	85176990

Other features

Specification	Value
Firewall throughput	6000 Mbit/s
VPN throughput	650 Mbit/s
