Securepoint RC1000R G5 (Rev. 1): Full Specifications

Overview

Connectivity: Wired
Type: 1U
Firewall throughput: 30 Gbit/s
Reset button: Yes
Number of users: 1000 user(s)
Security algorithms: AES

Brand: Securepoint
Category: Hardware Firewall
Model: RC1000R G5 (Rev. 1)
Part number: SP-UTM-11625
EAN / UPC: 4039407082209
Also known as: Securepoint RC1000R G5 Security UTM Appliance

Specifications

33 specifications in 12 groups

Data transmission

Specification	Value
Firewall throughput	30 Gbit/s
VPN throughput	3.5 Gbit/s

Performance

Specification	Value
Reset button	Yes

Network

Specification	Value
Number of users	1000 user(s)

Security

Specification	Value
Security algorithms	AES

Management features

Specification	Value
LED indicators	Yes
On/off switch	Yes

Ports & interfaces

Specification	Value
Connectivity technology	Wired
Gigabit Ethernet (copper) ports quantity	8
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Console port	RJ-45
Number of console ports	1
AC inlets quantity	2
Number of expansion slots	2
SFP module slots quantity	2
VGA (D-Sub) ports quantity	1

Storage

Specification	Value
Storage media type	SSD

Design

Specification	Value
Rack mounting	Yes
Form factor	1U
Built-in fan	Yes
Number of fans	3 fan(s)

Power

Specification	Value
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	360 W
Redundant power supply (RPS) support	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	10 - 80%

Weight & dimensions

Specification	Value
Width	430 mm
Depth	475 mm
Height	44 mm

Other features

Specification	Value
Firewall throughput	30000 Mbit/s
VPN throughput	3500 Mbit/s
