DFL-870 hardware firewall
Model DFL-870EAN 790069429293
30 specifications
- ConnectivityWired
- Weight1.7 kg
- IPSec VPN throughput1 Gbit/s
- Reset buttonYes
- Networking standardsIEEE 802.1Q
- Security algorithmsDES, HTTPS
Overview
- Connectivity
- Wired
- Weight
- 1.7 kg
- IPSec VPN throughput
- 1 Gbit/s
- Reset button
- Yes
- Networking standards
- IEEE 802.1Q
- Security algorithms
- DES, HTTPS
- Brand
- D-Link
- Category
- Hardware Firewall
- Model
- DFL-870
- Part number
- DFL-870
- EAN / UPC
- 790069429293
- Also known as
- D-Link DFL-870 hardware firewall
Specifications
30 specifications in 11 groups
Data transmission
| Specification | Value |
|---|---|
| IPSec VPN throughput | 1 Gbit/s |
| IPS/IDS throughput | 450 Mbit/s |
| Gateway antivirus throughput | 0.6 Gbit/s |
| Security policies (max) | 2000 |
| Load balancing | Yes |
Performance
| Specification | Value |
|---|---|
| Reset button | Yes |
| Mean time between failures (MTBF) | 374681 h |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1Q |
| VPN tunnels quantity | 200 |
| DHCP client | Yes |
| DHCP server | Yes |
| Number of VLANs | 128 |
| Point-to-point protocol over Ethernet (PPPoE) | Yes |
Security
| Specification | Value |
|---|---|
| Security algorithms | DES, HTTPS |
| DDoS protection | Yes |
Protocols
| Specification | Value |
|---|---|
| Routing protocols | OSPF |
Management features
| Specification | Value |
|---|---|
| LED indicators | Activity, Link, Power, Speed |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| USB 2.0 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 6 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100-240 V |
| Power consumption (max) | 20 W |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC Class A, CE Class A, VCCI |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 278 x 183 x 44 mm |
| Weight | 1.7 kg |
