VLHDMIMAT4X431-R AV extender AV receiver Black
Model VLHDMIMAT4X431-REAN 5704174240532
44 specifications
- ConnectivityWired
- TypeAV receiver
- Weight200 g
- ColourBlack
- Power source typeDC
- Operating relative humidity (H-H)10 - 90%
Overview
- Connectivity
- Wired
- Type
- AV receiver
- Weight
- 200 g
- Colour
- Black
- Power source type
- DC
- Operating relative humidity (H-H)
- 10 - 90%
- Brand
- Vivolink
- Category
- AV Extender
- Model
- VLHDMIMAT4X431-R
- Part number
- VLHDMIMAT4X431-R
- EAN / UPC
- 5704174240532
- Also known as
- Vivolink VLHDMIMAT4X431-R AV extender AV receiver Black
Specifications
44 specifications in 7 groups
Features
| Specification | Value |
|---|---|
| Type | AV receiver |
| Maximum resolution | 4096 x 2160 pixels |
| Cable types supported | Cat5e, Cat6a |
| Maximum transfer distance | 70 m |
| Maximum refresh rate | 60 Hz |
| Bidirectional | Yes |
| IR pass-through | Yes |
| Bandwidth | 18 Gbit/s |
| Consumer Electronics Control (CEC) support | Yes |
| HDCP | Yes |
| HDCP version | 2.2 |
| LED indicators | Power |
| Material | Metal |
| Product colour | Black |
| HDBaseT certified | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Ethernet LAN | Yes |
| RJ-45 input ports | 1 |
| HDBaseT port | Yes |
| HDMI version | 2.0 |
| Number of HDMI outputs | 1 |
| 3.5 mm (1/8-inch) in | Yes |
| 3.5 mm (1/8-inch) out | Yes |
| Remote (IR) input | 1 |
| Remote (IR) output | 1 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Operating voltage (receiver) | 24 V |
| Output current | 1.25 A |
| Power consumption (receiver) (max) | 9.5 W |
| External power adapter | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -10 - 55 °C |
| Storage temperature (T-T) | -25 - 70 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 74 mm |
| Depth | 120 mm |
| Height | 18 mm |
| Weight | 200 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package weight | 300 g |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
| Mounting kit | Yes |
