StarTech.com 4K HDMI over Fiber Extender Kit, 4K
StarTech.com

4K HDMI over Fiber Extender Kit, 4K

60Hz up to 3300ft/1km (Single Mode) or 1000ft/300m (Multimode) LC Fiber Optic, HDR, HDCP, 3.5mm Audio/RS232/IR

Model ST121HD20FXA2EAN 065030897303

60 specifications
  • ConnectivityWired
  • TypeAV transmitter & receiver
  • Weight280 g
  • ColourBlack
  • AC input voltage100 - 240 V
  • Operating relative humidity (H-H)20 - 90%
See all specifications

Overview

Connectivity
Wired
Type
AV transmitter & receiver
Weight
280 g
Colour
Black
AC input voltage
100 - 240 V
Operating relative humidity (H-H)
20 - 90%
Brand
StarTech.com
Category
AV Extender
Model
ST121HD20FXA2
Part number
ST121HD20FXA2
EAN / UPC
065030897303
Also known as
StarTech.com 4K HDMI over Fiber Extender Kit, 4K 60Hz up to 3300ft/1km (Single Mode) or 1000ft/300m (Multimode) LC Fiber Optic, HDR, HDCP, 3.5mm Audio/RS232/IR

Specifications

60 specifications in 9 groups

Features

TypeAV transmitter & receiver
Maximum resolution4096 x 2160 pixels
ChipsetSiFotonics SD1503/SD1513
Maximum transfer distance1000 m
High Dynamic Range (HDR) supportedYes
High Dynamic Range (HDR) technologyHigh Dynamic Range 10 (HDR10)
Fiber mode structureMulti-mode, Single-mode
Maximum refresh rate60 Hz
Extended display identification data (EDID)Yes
Audio output channels7.1 channels
Electrostatic Discharge (ESD) protectionYes
Electrostatic Discharge (ESD) protection8 kV
Infrared (IR) frequency range20 - 60 kHz
Bandwidth18 Gbit/s
Baud rate115.2 Kbit/s
HDCPYes
HDCP version2.2
LED indicatorsActivity, Power
Product colourBlack

Ports & interfaces

Connectivity technologyWired
HDMI in1
HDMI version2.1
Number of HDMI outputs2
Fiber optic connectorLC
Fiber ports quantity2
USB ports quantity2
USB connector typeMicro-USB B
Line outputs (RCA)1
Line-inYes
Remote (IR) input2
Remote (IR) output2
Serial interface typeRS-232
Serial ports quantity2
DC-in jackYes

Power

AC input voltage100 - 240 V
Operating voltage5 V
Input current0.35 A
Output current1 A
Power plug typeType M

Operational conditions

Operating relative humidity (H-H)20 - 90%
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C

Weight & dimensions

Width68 mm
Depth134 mm
Height18 mm
Weight280 g

Packaging data

Package width203 mm
Package depth303 mm
Package height65 mm
Package weight1 kg

Packaging content

AC adapter includedYes
Quick start guideYes
IR blaster includedYes
IR receiver includedYes

Technical details

Compliance certificatesCE, RoHS
Sustainability complianceYes

Logistics data

Master (outer) case width331 mm
Master (outer) case length330 mm
Master (outer) case height436 mm
Products per master (outer) case10 pc(s)
