Techly IDATA HDMI-WL20M10

Techly IDATA HDMI-WL20M10

Model IDATA HDMI-WL20M10EAN 8051128104820

35 specifications
  • ConnectivityWireless
  • TypeAV transmitter & receiver
  • ColourBlack
  • Input current2 A
  • Operating relative humidity (H-H)0 - 90%
  • Receiver dimensions (WxDxH)38.92 x 88.75 x 15.26 mm
See all specifications

Overview

Connectivity
Wireless
Type
AV transmitter & receiver
Colour
Black
Input current
2 A
Operating relative humidity (H-H)
0 - 90%
Receiver dimensions (WxDxH)
38.92 x 88.75 x 15.26 mm
Brand
Techly
Category
AV Extender
Model
IDATA HDMI-WL20M10
Part number
IDATA HDMI-WL20M10
EAN / UPC
8051128104820
Also known as
Techly IDATA HDMI-WL20M10 AV extender AV transmitter & receiver Black

Specifications

35 specifications in 7 groups

Features

TypeAV transmitter & receiver
Maximum resolution1920 x 1080 pixels
Maximum transfer distance20 m
Maximum refresh rate60 Hz
Bandwidth4.95 Gbit/s
HDCPYes
LED indicatorsYes
MaterialPlastic
Plug and PlayYes
Supported graphics resolutions720 x 480, 720 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Supported video modes480i, 480p, 576i, 576p, 720p, 1080p
Product colourBlack
CertificationCE, WEEE, RAEE

Ports & interfaces

Connectivity technologyWireless
HDMI in1
HDMI version1.3
Number of HDMI outputs1
USB ports quantity1
USB connector typeMicro-USB
DC-in jackYes

Power

Input current2 A
Operating voltage (transmitter)5 V
Power consumption (transmitter) (max)2.5 W
Power consumption (receiver) (max)5 W

Operational conditions

Operating relative humidity (H-H)0 - 90%
Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-10 - 70 °C

Weight & dimensions

Receiver dimensions (WxDxH)38.92 x 88.75 x 15.26 mm
Receiver weight20 g
Transmitter dimensions (WxDxH)85.58 x 138.11 x 19.18 mm
Transmitter weight120 g

Packaging content

AC adapter includedYes
Cables includedUSB
ManualYes

Technical details

Compliance certificatesRoHS
