IDATA HDMI-EX60-H2
Model IDATA HDMI-EX60-H2EAN 8059018361308
41 specifications
- ConnectivityWired
- TypeAV transmitter & receiver
- Weight420 g
- ColourBlack
- Power source typeDC
- Operating relative humidity (H-H)10 - 90%
Overview
- Connectivity
- Wired
- Type
- AV transmitter & receiver
- Weight
- 420 g
- Colour
- Black
- Power source type
- DC
- Operating relative humidity (H-H)
- 10 - 90%
- Brand
- Techly
- Category
- AV Extender
- Model
- IDATA HDMI-EX60-H2
- Part number
- IDATA HDMI-EX60-H2
- EAN / UPC
- 8059018361308
- Also known as
- Techly HDMI 4K 18G HDR Extender Set up to 70 m over Cat6
Specifications
41 specifications in 7 groups
Features
| Specification | Value |
|---|---|
| Type | AV transmitter & receiver |
| Maximum resolution | 4096 x 2160 pixels |
| Cable types supported | Cat5e, Cat6 |
| Maximum transfer distance | 70 m |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10) |
| Extended display identification data (EDID) | Yes |
| Bidirectional | Yes |
| IR pass-through | Yes |
| Audio formats supported | DTS, LPCM |
| HDCP | Yes |
| HDCP version | 2.2 |
| Supported video modes | 1080p |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| HDMI in | 1 |
| HDMI version | 2.0 |
| Number of HDMI outputs | 2 |
| Remote (IR) input | 2 |
| Remote (IR) output | 2 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Operating voltage | 12 V |
| Input current | 1 A |
| Power consumption (typical) | 4 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 5 - 55 °C |
| Storage temperature (T-T) | -25 - 70 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 80 mm |
| Depth | 80 mm |
| Height | 16.8 mm |
| Weight | 420 g |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| IR emitter included | Yes |
| IR extender included | Yes |
| Manual | Yes |
Supplier features
| Specification | Value |
|---|---|
| Vendor code | 361308 |
