Techly IDATA EXT-E223
Techly

IDATA EXT-E223

Model IDATA EXT-E223EAN 8059018363005

47 specifications
  • ConnectivityWired
  • TypeAV transmitter & receiver
  • Weight525 g
  • ColourBlack
  • Power source typeDC
  • Operating relative humidity (H-H)0 - 90%
See all specifications

Overview

Connectivity
Wired
Type
AV transmitter & receiver
Weight
525 g
Colour
Black
Power source type
DC
Operating relative humidity (H-H)
0 - 90%
Brand
Techly
Category
AV Extender
Model
IDATA EXT-E223
Part number
IDATA EXT-E223
EAN / UPC
8059018363005
Also known as
Techly HDMI Extender 1080p on Cat.6/6A/7 Cable up to 70m with EDID

Specifications

47 specifications in 8 groups

Features

TypeAV transmitter & receiver
Maximum resolution1920 x 1080 pixels
Cable types supportedCat6, Cat6a, Cat7
Maximum transfer distance70 m
High Dynamic Range (HDR) supportedYes
High Dynamic Range (HDR) technologyHigh Dynamic Range 10 (HDR10)
Maximum refresh rate60 Hz
Extended display identification data (EDID)Yes
IR pass-throughYes
Electrostatic Discharge (ESD) protectionYes
Infrared (IR) frequency range20 - 60 kHz
Audio formats supportedDTS, LPCM, PCM
HDCPYes
HDCP version1.4
LED indicatorsPower
MaterialAluminium
Supported graphics resolutions800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 960, 1366 x 768, 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
Supported video modes480p, 576i, 576p, 720p, 1080i, 1080p
Product colourBlack

Ports & interfaces

Connectivity technologyWired
RJ-45 input ports1
RJ-45 output ports1
HDMI in1
HDMI version1.3
Number of HDMI outputs2
Audio (L/R) out1
Remote (IR) input2
Remote (IR) output2
DC-in jackYes

Power

Power source typeDC
Operating voltage5 V
Power consumption (TX)2.5 W
Power consumption (RX)2.5 W

Operational conditions

Operating relative humidity (H-H)0 - 90%
Operating temperature (T-T)-20 - 60 °C
Storage temperature (T-T)-30 - 70 °C

Weight & dimensions

Width75 mm
Depth80 mm
Height18 mm
Weight525 g

Packaging content

AC adapter includedYes
ManualYes
IR blaster includedYes
IR receiver includedYes

Supplier features

Vendor code363005

Technical details

Compliance certificatesCE
Audio supportYes
