Techly IDATA EX-HL81TY

IDATA EX-HL81TY

Model IDATA EX-HL81TYEAN 8054529028207

46 specifications

TypeAV transmitter & receiver
Weight2.18 kg
ColourBlack
RJ-45 input ports1
Operating voltage12 V
Operating temperature (T-T)0 - 60 °C

See all specifications

Overview

Type: AV transmitter & receiver
Weight: 2.18 kg
Colour: Black
RJ-45 input ports: 1
Operating voltage: 12 V
Operating temperature (T-T): 0 - 60 °C

Brand: Techly
Category: AV Extender
Model: IDATA EX-HL81TY
Part number: IDATA EX-HL81TY
EAN / UPC: 8054529028207
Also known as: Techly HDMI 1x8 Extender Splitter over CAT6/6a/7 50m with IR pass-back IDATA EX-HL81TY

Specifications

46 specifications in 8 groups

Features

Specification	Value
Type	AV transmitter & receiver
Maximum resolution	1920 x 1080 pixels
Cable types supported	Cat6, Cat6a, Cat7
Maximum transfer distance	40 m
Maximum refresh rate	60 Hz
3D	No
Audio formats supported	PCM
Colour depth	36 bit
HDCP	Yes
HDCP & EDID bypass	Yes
HDCP version	1.2
LED indicators	Yes
Material	Aluminium
Plug and Play	Yes
Remote control type	IR
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Wall mountable	Yes
Product colour	Black
Certification	CE, FCC

Ports & interfaces

Specification	Value
RJ-45 input ports	1
RJ-45 output ports	8
HDMI in	1
HDMI version	1.3
Number of HDMI outputs	9
Remote (IR) input	1
Remote (IR) output	1
DC-in jack	Yes

Power

Specification	Value
Operating voltage	12 V
Input current	3 A
Operating voltage (receiver)	5 V
Power consumption (typical)	24 W
External power adapter	Yes
Power over Ethernet (PoE)	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 60 °C
Storage relative humidity (H-H)	0 - 95%
Storage temperature (T-T)	-20 - 70 °C

Weight & dimensions

Specification	Value
Weight	2.18 kg
Receiver dimensions (WxDxH)	71.6 x 66.6 x 22.6 mm
Transmitter dimensions (WxDxH)	276 x 95.98 x 23 mm

Packaging content

Specification	Value
AC adapter included	Yes
Cables included	IR
Quick start guide	Yes
IR blaster included	Yes

Supplier features

Specification	Value
Vendor code	028207

Technical details

Specification	Value
Compliance certificates	CE
Audio support	Yes
