HDMI over IP Extender - 1080p
60Hz HDMI Video over Ethernet/LAN Extender through Network Switch - Transmitter/Receiver Kit - up to 490ft (150m) ove
Model ST12MHDLNVEAN 065030887359
45 specifications
- ConnectivityWired
- TypeAV transmitter & receiver
- Weight474 g
- ColourBlack
- AC input voltage100 - 240 V
- Operating relative humidity (H-H)0 - 95%
Overview
- Connectivity
- Wired
- Type
- AV transmitter & receiver
- Weight
- 474 g
- Colour
- Black
- AC input voltage
- 100 - 240 V
- Operating relative humidity (H-H)
- 0 - 95%
- Brand
- StarTech.com
- Category
- AV Extender
- Model
- ST12MHDLNV
- Part number
- ST12MHDLNV
- EAN / UPC
- 065030887359
- Also known as
- StarTech.com HDMI over IP Extender - 1080p 60Hz HDMI Video over Ethernet/LAN Extender through Network Switch - Transmitter/Receiver Kit - up to 490ft (150m) ove
Specifications
45 specifications in 9 groups
Features
| Specification | Value |
|---|---|
| Type | AV transmitter & receiver |
| Maximum resolution | 1920 x 1080 pixels |
| Cable types supported | Cat5e, Cat6 |
| Maximum transfer distance | 150 m |
| Maximum refresh rate | 60 Hz |
| Daisy chain | Yes |
| HDCP | Yes |
| HDCP version | 1.4 |
| LED indicators | Power |
| Rubber feet | Yes |
| Product colour | Black |
| Certification | CE, FCC, REACH |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Wi-Fi | No |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 2 |
| HDMI in | 1 |
| Number of HDMI outputs | 2 |
| 3.5 mm (1/8-inch) in | Yes |
| 3.5 mm (1/8-inch) out | Yes |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| Operating voltage | 12 V |
| Output current | 1.5 A |
| External power adapter | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | 0 - 70 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 70 mm |
| Depth | 125 mm |
| Height | 26 mm |
| Weight | 474 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 255 mm |
| Package depth | 306 mm |
| Package height | 67 mm |
| Package weight | 1.26 kg |
Packaging content
| Specification | Value |
|---|---|
| Included power plug types | AU, EU, NA, UK |
| Manual | Yes |
| IR blaster included | Yes |
| IR receiver included | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176200 |
| Master (outer) case width | 320 mm |
| Master (outer) case length | 368 mm |
| Master (outer) case height | 280 mm |
| Products per master (outer) case | 5 pc(s) |
