VGA Video Extender over Cat5 (ST121 Series) - TAA
Model ST121UTPEAN 006503079123
37 specifications
- ConnectivityWired
- TypeAV transmitter & receiver
- Weight335 g
- ColourBlack
- Operating voltage9 V
- Operating relative humidity (H-H)0 - 80%
Overview
- Connectivity
- Wired
- Type
- AV transmitter & receiver
- Weight
- 335 g
- Colour
- Black
- Operating voltage
- 9 V
- Operating relative humidity (H-H)
- 0 - 80%
- Brand
- StarTech.com
- Category
- AV Extender
- Model
- ST121UTP
- Part number
- ST121UTP
- EAN / UPC
- 006503079123, 065030791236
- Also known as
- StarTech.com VGA Video Extender over Cat5 (ST121 Series) - TAA
Specifications
37 specifications in 9 groups
Features
| Specification | Value |
|---|---|
| Type | AV transmitter & receiver |
| Maximum resolution | 1440 x 900 pixels |
| Cable types supported | Cat5e, Cat6 |
| Maximum transfer distance | 150 m |
| Material | Aluminium |
| Rubber feet | Yes |
| Supported graphics resolutions | 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1440 x 900 (WXGA+) |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| VGA (D-Sub) input ports | 1 |
| VGA (D-Sub) output ports | 4 |
Power
| Specification | Value |
|---|---|
| Operating voltage | 9 V |
| Output current | 0.6 A |
| Power consumption (typical) | 5.4 W |
| Power plug type | Type M |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 80% |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 83 mm |
| Depth | 60 mm |
| Height | 20 mm |
| Weight | 335 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 242 mm |
| Package depth | 188 mm |
| Package height | 93 mm |
| Package weight | 800 g |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Manual | Yes |
| Mounting brackets included | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE |
| Sustainability compliance | Yes |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case width | 515 mm |
| Master (outer) case length | 412 mm |
| Master (outer) case height | 322 mm |
| Products per master (outer) case | 12 pc(s) |
