HDMI Over Fiber Extender - YUV4:4:4 - 4K
60Hz
Model ST121HD20FXAEAN 065030885034
50 specifications
- ConnectivityWired
- TypeAV transmitter & receiver
- Weight900 g
- ColourBlack
- AC input voltage100 - 240 V
- Operating relative humidity (H-H)0 - 80%
Overview
- Connectivity
- Wired
- Type
- AV transmitter & receiver
- Weight
- 900 g
- Colour
- Black
- AC input voltage
- 100 - 240 V
- Operating relative humidity (H-H)
- 0 - 80%
- Brand
- StarTech.com
- Category
- AV Extender
- Model
- ST121HD20FXA
- Part number
- ST121HD20FXA
- EAN / UPC
- 065030885034, 5704174642053
- Also known as
- StarTech.com HDMI Over Fiber Extender - YUV4:4:4 - 4K 60Hz
Specifications
50 specifications in 9 groups
Features
| Specification | Value |
|---|---|
| Type | AV transmitter & receiver |
| Maximum resolution | 4096 x 2160 pixels |
| Maximum transfer distance | 1000 m |
| Maximum refresh rate | 60 Hz |
| Audio output channels | 7.1 channels |
| Bandwidth | 18 Gbit/s |
| Carrier frequency | 38 kHz |
| Daisy chain | No |
| Material | Steel |
| Rack mounting | Yes |
| Rubber feet | Yes |
| Product colour | Black |
| Certification | REACH, CE, FCC |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| HDMI in | 1 |
| Number of HDMI outputs | 1 |
| Fiber optic connector | LC |
| USB ports quantity | 2 |
| USB connector type | Mini-USB B |
| Remote (IR) input | 2 |
| Remote (IR) output | 2 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| Operating voltage | 5 V |
| Output current | 1 A |
| Power consumption (typical) | 3 W |
| External power adapter | Yes |
| Power plug type | Type M |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 80% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 66 mm |
| Depth | 100 mm |
| Height | 26 mm |
| Weight | 900 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 248 mm |
| Package depth | 183 mm |
| Package height | 55 mm |
| Package weight | 915 g |
Packaging content
| Specification | Value |
|---|---|
| Cables included | Fiber |
| Included power plug types | AU, EU, NA, UK |
| Manual | Yes |
| IR blaster included | Yes |
| IR receiver included | Yes |
| Mounting brackets included | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case width | 514 mm |
| Master (outer) case length | 300 mm |
| Master (outer) case height | 388 mm |
| Products per master (outer) case | 20 pc(s) |
