150m Cat.6 TosLink (Optical) and Coaxial Digital Audio Extender
Model 70456EAN 4002888704564
35 specifications
- ConnectivityWired
- TypeAV transmitter & receiver
- ColourBlack
- Operating voltage (transmitter)12 V
- Operating relative humidity (H-H)5 - 90%
- Receiver dimensions (WxDxH)65.9 x 26.9 x 53.1 mm
Overview
- Connectivity
- Wired
- Type
- AV transmitter & receiver
- Colour
- Black
- Operating voltage (transmitter)
- 12 V
- Operating relative humidity (H-H)
- 5 - 90%
- Receiver dimensions (WxDxH)
- 65.9 x 26.9 x 53.1 mm
- Brand
- Lindy
- Category
- AV Extender
- Model
- 70456
- Part number
- 70456
- EAN / UPC
- 4002888704564
- Also known as
- Lindy 150m Cat.6 TosLink (Optical) and Coaxial Digital Audio Extender
Specifications
35 specifications in 8 groups
Features
| Specification | Value |
|---|---|
| Type | AV transmitter & receiver |
| Cable types supported | Cat5e, Cat6 |
| Chipset | EL5171/ EL5172 |
| Maximum transfer distance | 150 m |
| Audio formats supported | DTS, LPCM |
| Material | Metal |
| Product colour | Black |
| Certification | CE, FCC, RoHS, REACH & California Proposition 65 |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| Digital audio coaxial in | 1 |
| Digital audio coaxial out | 1 |
| Digital audio optical in | 1 |
| Digital audio optical input type | TOSLINK |
| Digital audio optical out | 1 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Operating voltage (transmitter) | 12 V |
| Current | 1.25 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 5 - 90% |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -10 - 80 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Receiver dimensions (WxDxH) | 65.9 x 26.9 x 53.1 mm |
| Receiver weight | 168 g |
| Transmitter dimensions (WxDxH) | 65.9 x 26.9 x 53.1 mm |
| Transmitter weight | 168 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 190 mm |
| Package depth | 60 mm |
| Package height | 145 mm |
| Package weight | 405 g |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Included power plug types | EU, UK, US |
| Manual | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
