SDVoE Controller
Model 38364EAN 4002888383646
44 specifications
- ConnectivityWired
- TypeAV repeater
- Weight760 g
- ColourBlack
- Power source typeDC
- Operating relative humidity (H-H)20 - 90%
Overview
- Connectivity
- Wired
- Type
- AV repeater
- Weight
- 760 g
- Colour
- Black
- Power source type
- DC
- Operating relative humidity (H-H)
- 20 - 90%
- Brand
- Lindy
- Category
- AV Extender
- Model
- 38364
- Part number
- 38364
- EAN / UPC
- 4002888383646
- Also known as
- Lindy SDVoE Controller
Specifications
44 specifications in 8 groups
Features
| Specification | Value |
|---|---|
| Type | AV repeater |
| Maximum resolution | 3840 x 2160 pixels |
| Cable types supported | Cat6 |
| Maximum transfer distance | 100 m |
| Maximum refresh rate | 60 Hz |
| Supported network protocols | IP |
| Material | Metal |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Ethernet LAN | Yes |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| USB ports quantity | 1 |
| USB connector type | Micro-USB |
| RS-232 input ports | 2 |
| 3.5 mm (1/8-inch) in | Yes |
| 3.5 mm (1/8-inch) out | Yes |
| Remote (IR) input | 1 |
| Remote (IR) output | 1 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| Operating voltage | 12 V |
| Output current | 1 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 20 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 20 - 90% |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 204 mm |
| Depth | 98.5 mm |
| Height | 21.5 mm |
| Weight | 760 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 255 mm |
| Package depth | 157 mm |
| Package height | 77 mm |
| Package weight | 960 g |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | IR |
| Quick start guide | Yes |
| Mounting kit | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), REACH, RoHS, UKCA |
| Special features | API support, 4 channel GPIO control ports (5V/12V optional level) |
| Sustainability compliance | Yes |
