Lindy 150m Cat.6 4x4 HDMI 4K60 HDBaseT Matrix Extender
Lindy

150m Cat.6 4x4 HDMI 4K60 HDBaseT Matrix Extender

Model 38345EAN 4002888383455

52 specifications
  • ConnectivityWired
  • TypeAV transmitter & receiver
  • Weight5.31 kg
  • ColourBlack
  • Power source typeAC
  • Operating relative humidity (H-H)20 - 90%
See all specifications

Overview

Connectivity
Wired
Type
AV transmitter & receiver
Weight
5.31 kg
Colour
Black
Power source type
AC
Operating relative humidity (H-H)
20 - 90%
Brand
Lindy
Category
AV Extender
Model
38345
Part number
38345
EAN / UPC
4002888383455
Also known as
Lindy 150m Cat.6 4x4 HDMI 4K60 HDBaseT Matrix Extender

Specifications

52 specifications in 8 groups

Features

TypeAV transmitter & receiver
Maximum resolution3840 x 2160 pixels
Cable types supportedCat6
Maximum transfer distance150 m
High Dynamic Range (HDR) supportedYes
EDID managementYes
HDCP pass-throughYes
Infrared (IR) frequency range20 - 60 kHz
Audio formats supportedLPCM
Bandwidth18 Gbit/s
HDCPYes
HDCP version2.2
MaterialMetal
On/off switchYes
Signal-to-Noise Ratio (SNR)90 dB
Supported video modes1080p
Product colourBlack
CertificationCalifornia Proposition 65

Ports & interfaces

Connectivity technologyWired
RJ-45 output ports4
HDBaseT portYes
HDMI in4
HDMI version2.0
Number of HDMI outputs5
RS-232 input ports2
Digital audio coaxial out4
3.5 mm (1/8-inch) inYes
3.5 mm (1/8-inch) outYes
Audio (L/R) out4
Audio RCA outputs4

Power

Power source typeAC
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Power requirements60 W

Operational conditions

Operating relative humidity (H-H)20 - 90%
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C

Weight & dimensions

Width440 mm
Depth200 mm
Height45 mm
Weight5.31 kg
Receiver dimensions (WxDxH)140 x 65 x 18 mm

Packaging data

Package width510 mm
Package depth401 mm
Package height98 mm
Package weight6.33 kg
Package typeBox

Packaging content

ManualYes
Packaging content4x4 HDBaseT Extender Matrix - Transmitter 4 x HDBaseT Receivers 5 x IR Emitter Cable, 1.5m 5 x IR Receiver Cable, 1.5m 10 x Mounting Ears & Screws 4 x 3-Pin Terminal Block 4 x 5-Pin Terminal Block RS-232 Male to Female cable, 1.5m 4 x mains cables (EU, UK, US & AUS), 1.5m Lindy Manual

Technical details

Compliance certificatesCE, Federal Communications Commission (FCC), REACH, RoHS, UKCA
Sustainability complianceYes
Warranty period2 year(s)
