100m Cat.6 HDMI 4K60, IR and RS-232 HDBaseT Extender, Receiver
Model 38207EAN 4002888382076
41 specifications
- ConnectivityWired
- TypeAV receiver
- Weight315 g
- ColourBlack
- Operating voltage24 V
- Operating relative humidity (H-H)20 - 90%
Overview
- Connectivity
- Wired
- Type
- AV receiver
- Weight
- 315 g
- Colour
- Black
- Operating voltage
- 24 V
- Operating relative humidity (H-H)
- 20 - 90%
- Brand
- Lindy
- Category
- AV Extender
- Model
- 38207
- Part number
- 38207
- EAN / UPC
- 4002888382076
- Also known as
- Lindy 100m Cat.6 HDMI 4K60, IR and RS-232 HDBaseT Extender, Receiver
Specifications
41 specifications in 7 groups
Features
| Specification | Value |
|---|---|
| Type | AV receiver |
| Maximum resolution | 3840 x 2160 pixels |
| Cable types supported | Cat6 |
| Chipset | VS100 |
| Maximum transfer distance | 150 m |
| Maximum refresh rate | 60 Hz |
| Bidirectional | Yes |
| CEC pass-through | Yes |
| Bandwidth | 18 Gbit/s |
| HDCP | Yes |
| HDCP version | 2.2 |
| Material | Metal |
| Supported graphics resolutions | 1280 x 720 (HD 720), 3840 x 2160 |
| Product colour | Black |
| HDBaseT certified | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| RJ-45 input ports | 1 |
| HDBaseT port | Yes |
| Number of HDMI outputs | 1 |
| USB ports quantity | 1 |
| Audio input | 1 |
| Remote (IR) input | 1 |
| Remote (IR) output | 1 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Operating voltage | 24 V |
| Input current | 1 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 20 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 140 mm |
| Depth | 65 mm |
| Height | 18 mm |
| Weight | 315 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 220 mm |
| Package depth | 70 mm |
| Package height | 130 mm |
| Package weight | 847 g |
Packaging content
| Specification | Value |
|---|---|
| Cables included | IR |
| Manual | Yes |
| IR receiver included | Yes |
