38206 AV extender AV transmitter Black
Model 38206EAN 4002888382069
42 specifications
- ConnectivityWired
- TypeAV transmitter
- Weight315 g
- ColourBlack
- Operating voltage24 V
- Operating relative humidity (H-H)20 - 90%
Overview
- Connectivity
- Wired
- Type
- AV transmitter
- Weight
- 315 g
- Colour
- Black
- Operating voltage
- 24 V
- Operating relative humidity (H-H)
- 20 - 90%
- Brand
- Lindy
- Category
- AV Extender
- Model
- 38206
- Part number
- 38206
- EAN / UPC
- 4002888382069
- Also known as
- Lindy 38206 AV extender AV transmitter Black
Specifications
42 specifications in 8 groups
Features
| Specification | Value |
|---|---|
| Type | AV transmitter |
| Maximum resolution | 3840 x 2160 pixels |
| Cable types supported | Cat6 |
| Chipset | VS100 |
| Maximum transfer distance | 150 m |
| Maximum refresh rate | 60 Hz |
| Consumer Electronics Control (CEC) support | Yes |
| HDCP | Yes |
| HDCP & EDID bypass | Yes |
| HDCP version | 2.2 |
| Material | Metal |
| Supported graphics resolutions | 1280 x 720 (HD 720), 3840 x 2160 |
| Product colour | Black |
| HDBaseT certified | Yes |
| Certification | CE, FCC, REACH |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| HDBaseT port | Yes |
| HDMI in | 1 |
| HDMI version | 2.0 |
| Number of HDMI outputs | 1 |
| Remote (IR) input | 1 |
| Remote (IR) output | 1 |
Power
| Specification | Value |
|---|---|
| Operating voltage | 24 V |
| Current | 1 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 20 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 140 mm |
| Depth | 65 mm |
| Height | 18 mm |
| Weight | 315 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 220 mm |
| Package depth | 70 mm |
| Package height | 130 mm |
| Package weight | 847 g |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | IR |
| Manual | Yes |
| Mounting brackets included | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
