Cascadeable HDMI CAT6 Extender - Transmitter Unit
Model 38140EAN 4002888381406
29 specifications
- ConnectivityWired
- Weight200 g
- ColourBlack
- Maximum resolution192 x 1080 pixels
- AC input voltage5 V
- Operating temperature (T-T)0 - 60 °C
Overview
- Connectivity
- Wired
- Weight
- 200 g
- Colour
- Black
- Maximum resolution
- 192 x 1080 pixels
- AC input voltage
- 5 V
- Operating temperature (T-T)
- 0 - 60 °C
- Brand
- Lindy
- Category
- AV Extender
- Model
- 38140
- Part number
- 38140
- EAN / UPC
- 4002888381406
- Also known as
- Lindy Cascadeable HDMI CAT6 Extender - Transmitter Unit
Specifications
29 specifications in 7 groups
Features
| Specification | Value |
|---|---|
| Maximum resolution | 192 x 1080 pixels |
| Cable types supported | Cat5e, Cat6, Cat7 |
| Maximum transfer distance | 150 m |
| Audio output channels | 2.0 channels |
| 3D | No |
| Audio formats supported | LPCM |
| HDCP | Yes |
| LED indicators | Link, Power |
| Plug and Play | Yes |
| Supported video modes | 1080p |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Ethernet LAN | Yes |
| RJ-45 output ports | 1 |
| HDMI in | 1 |
| HDMI version | 1.3 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| AC input voltage | 5 V |
| Input current | 2.6 A |
| External power adapter | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 60 °C |
| Storage temperature (T-T) | -20 - 70 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 67 mm |
| Depth | 140 mm |
| Height | 27 mm |
| Weight | 200 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Manual | Yes |
