VE8950T AV extender AV transmitter Black
Model VE8950TEAN 672792007576
41 specifications
- ConnectivityWired
- TypeAV transmitter
- Weight500 g
- ColourBlack
- Operating voltage5 V
- Operating relative humidity (H-H)0 - 95%
Overview
- Connectivity
- Wired
- Type
- AV transmitter
- Weight
- 500 g
- Colour
- Black
- Operating voltage
- 5 V
- Operating relative humidity (H-H)
- 0 - 95%
- Brand
- ATEN
- Category
- AV Extender
- Model
- VE8950T
- Part numbers
- VE8950T, VE8950T-AT-E
- EAN / UPC
- 672792007576, 5715327001023
- Also known as
- ATEN VE8950T AV extender AV transmitter Black
Specifications
41 specifications in 7 groups
Features
| Specification | Value |
|---|---|
| Type | AV transmitter |
| Maximum resolution | 4096 x 2160 pixels |
| Cable types supported | Cat5e, Cat6 |
| Maximum transfer distance | 100 m |
| Audio system | stereo |
| Baud rate | 19.2 Kbit/s |
| Control type | Buttons |
| Daisy chain | Yes |
| Firmware upgradeable | Yes |
| HDCP | Yes |
| Impedance | 100 Ω |
| LED indicators | Yes |
| Material | Metal |
| Supported graphics resolutions | 3840 x 2160, 4096 x 2160 |
| Supported video modes | 1080p |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| RJ-45 output ports | 1 |
| HDMI in | 1 |
| USB ports quantity | 1 |
| USB version | 2.0 |
| USB connector type | USB Type-B |
| Video in | 1 |
| Audio input | 1 |
| Remote (IR) input | 1 |
| Serial interface type | RS-232 |
| Serial ports quantity | 1 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Operating voltage | 5 V |
| Power consumption (typical) | 3.08 W |
| External power adapter | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 136 mm |
| Depth | 101 mm |
| Height | 29.6 mm |
| Weight | 500 g |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Manual | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
