VE802T-AT-E AV extender AV transmitter Black
Model VE802T-AT-EEAN 4719264642821
30 specifications
- ConnectivityWired
- TypeAV transmitter
- ColourBlack
- AC input frequency60 Hz
- Operating relative humidity (H-H)0 - 80%
- Transmitter dimensions (WxDxH)123 x 144.8 x 30 mm
Overview
- Connectivity
- Wired
- Type
- AV transmitter
- Colour
- Black
- AC input frequency
- 60 Hz
- Operating relative humidity (H-H)
- 0 - 80%
- Transmitter dimensions (WxDxH)
- 123 x 144.8 x 30 mm
- Brand
- ATEN
- Category
- AV Extender
- Model
- VE802T-AT-E
- Part number
- VE802T-AT-E
- EAN / UPC
- 4719264642821, 5052186087943
- Also known as
- ATEN VE802T-AT-E AV extender AV transmitter Black
Specifications
30 specifications in 7 groups
Features
| Specification | Value |
|---|---|
| Type | AV transmitter |
| Maximum resolution | 4096 x 2160 pixels |
| Cable types supported | Cat5, Cat6, Cat6a |
| Maximum transfer distance | 70 m |
| Bandwidth | 340 MHz |
| Consumer Electronics Control (CEC) support | Yes |
| HDCP | Yes |
| Impedance | 100 Ω |
| Material | Metal |
| Supported graphics resolutions | 4096 x 2160 |
| Supported video modes | 2160p |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| HDMI in | 1 |
| Number of HDMI outputs | 1 |
| RS-232 output ports | 1 |
| Video in | 1 |
| Video out | 1 |
| Remote (IR) output | 1 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| AC input frequency | 60 Hz |
| Operating voltage | 5 V |
| Power consumption (transmitter) (max) | 3.6 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 80% |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Transmitter dimensions (WxDxH) | 123 x 144.8 x 30 mm |
| Transmitter weight | 440 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
