VE800R
Model VE800REAN 672792003196
20 specifications
- TypeAV receiver
- Weight160 g
- ColourBlack, White
- RJ-45 input ports1
- Operating voltage5 V
- Operating relative humidity (H-H)0 - 80%
Overview
- Type
- AV receiver
- Weight
- 160 g
- Colour
- Black, White
- RJ-45 input ports
- 1
- Operating voltage
- 5 V
- Operating relative humidity (H-H)
- 0 - 80%
- Brand
- ATEN
- Category
- AV Extender
- Model
- VE800R
- Part number
- VE800R
- EAN / UPC
- 672792003196, 5054484473671, 6727920031962
- Also known as
- ATEN AT-VE800R
Specifications
20 specifications in 6 groups
Features
| Specification | Value |
|---|---|
| Type | AV receiver |
| Maximum resolution | 1920 x 1200 pixels |
| Cable types supported | Cat5, Cat5e |
| Maximum transfer distance | 60 m |
| LED indicators | Yes |
| Supported graphics resolutions | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA) |
| Supported video modes | 1080i, 1080p, 480p, 720p |
| Product colour | Black, White |
Ports & interfaces
| Specification | Value |
|---|---|
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| Number of HDMI outputs | 1 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Operating voltage | 5 V |
| External power adapter | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 80% |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 90 x 55 x 24 mm |
| Weight | 160 g |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
