VE602 DVI Dual Link/Audio Cat 5 Extender (2560 x 1600@40m)
Model VE602EAN 672792004544
23 specifications
- TypeAV transmitter & receiver
- ColourBlack
- DVI input ports1
- Power consumption (TX)2.4 W
- Operating relative humidity (H-H)0 - 80%
- Receiver dimensions (WxDxH)56 x 24 x 91.3 mm
Overview
- Type
- AV transmitter & receiver
- Colour
- Black
- DVI input ports
- 1
- Power consumption (TX)
- 2.4 W
- Operating relative humidity (H-H)
- 0 - 80%
- Receiver dimensions (WxDxH)
- 56 x 24 x 91.3 mm
- Brand
- ATEN
- Category
- AV Extender
- Model
- VE602
- Part number
- VE602
- EAN / UPC
- 672792004544, 4719264640261, 6727920045440
- Also known as
- ATEN VE602 DVI Dual Link/Audio Cat 5 Extender (2560 x 1600@40m)
Specifications
23 specifications in 5 groups
Features
| Specification | Value |
|---|---|
| Type | AV transmitter & receiver |
| Maximum resolution | 2560 x 1600 pixels |
| Cable types supported | Cat5e |
| Maximum transfer distance | 60 m |
| Bandwidth | 225 MHz |
| Bandwidth | 6.75 Gbit/s |
| Impedance | 100 Ω |
| Supported graphics resolutions | 1280 x 1024 (SXGA), 1920 x 1200 (WUXGA), 2560 x 1600 (WQXGA) |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| DVI input ports | 1 |
| DVI output ports | 1 |
| Audio input | 1 |
| Audio output | 1 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (TX) | 2.4 W |
| Power consumption (RX) | 2.86 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 80% |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Receiver dimensions (WxDxH) | 56 x 24 x 91.3 mm |
| Receiver weight | 180 g |
| Transmitter dimensions (WxDxH) | 56 x 24 x 91.3 mm |
| Transmitter weight | 180 g |
