VE2812EUT AV extender AV transmitter White
Model VE2812EUTEAN 4719264647383
30 specifications
- ConnectivityWired
- TypeAV transmitter
- Weight350 g
- ColourWhite
- Power consumption (transmitter) (max)3.14 W
- Operating relative humidity (H-H)0 - 80%
Overview
- Connectivity
- Wired
- Type
- AV transmitter
- Weight
- 350 g
- Colour
- White
- Power consumption (transmitter) (max)
- 3.14 W
- Operating relative humidity (H-H)
- 0 - 80%
- Brand
- ATEN
- Category
- AV Extender
- Model
- VE2812EUT
- Part number
- VE2812EUT
- EAN / UPC
- 4719264647383
- Also known as
- ATEN VE2812EUT AV extender AV transmitter White
Specifications
30 specifications in 5 groups
Features
| Specification | Value |
|---|---|
| Type | AV transmitter |
| Maximum resolution | 4096 x 2160 pixels |
| Cable types supported | Cat5e, Cat6, Cat6a |
| Maximum transfer distance | 150 m |
| Maximum refresh rate | 60 Hz |
| Bandwidth | 340 MHz |
| Bandwidth | 81.6 Gbit/s |
| HDCP | Yes |
| Impedance | 100 Ω |
| Material | Metal |
| Supported graphics resolutions | 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 3840 x 2160, 4096 x 2160 |
| Wall mountable | Yes |
| Product colour | White |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Ethernet LAN | Yes |
| VGA (D-Sub) input ports | 1 |
| HDMI in | 1 |
| RS-232 input ports | 1 |
| 3.5 mm (1/8-inch) in | Yes |
| AUX in | Yes |
| Audio (L/R) out | 1 |
| VGA (D-Sub) ports quantity | 1 |
Power
| Specification | Value |
|---|---|
| Power consumption (transmitter) (max) | 3.14 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 80% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 108 mm |
| Depth | 50 mm |
| Height | 51.7 mm |
| Weight | 350 g |
