ATEN VE1843-AT-E AV extender AV repeater Black
ATEN

VE1843-AT-E AV extender AV repeater Black

Model VE1843-AT-E

55 specifications
  • ConnectivityWired
  • TypeAV repeater
  • Weight640 g
  • ColourBlack
  • Operating relative humidity (H-H)0 - 80%
  • Width150.9 mm
See all specifications

Overview

Connectivity
Wired
Type
AV repeater
Weight
640 g
Colour
Black
Operating relative humidity (H-H)
0 - 80%
Width
150.9 mm
Brand
ATEN
Category
AV Extender
Model
VE1843-AT-E
Part number
VE1843-AT-E
Also known as
ATEN VE1843-AT-E AV extender AV repeater Black

Specifications

55 specifications in 8 groups

Features

TypeAV repeater
Maximum resolution4096 x 2160 pixels
Cable types supportedCat6a
Maximum transfer distance100 m
Maximum refresh rate240 Hz
Front panel control (RX)Yes
Front panel control (TX)Yes
Infrared (IR) frequency range30 - 56 kHz
3DYes
Bandwidth18 Gbit/s
Bandwidth600 MHz
HDCPYes
HDCP version2.2
Impedance100 Ω
LED indicatorsYes
MaterialMetal
Rubber feetYes
Supported graphics resolutions640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1400 x 1050 (SXGA+), 1400 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 3840 x 2160, 4096 x 2160
Product colourBlack

Ports & interfaces

Connectivity technologyWired
Ethernet LANYes
RJ-45 input ports1
RJ-45 output ports1
HDBaseT portYes
HDMI in1
Number of HDMI outputs1
USB ports quantity2
USB version2.0
USB connector typeUSB Type-A, USB Type-B
Audio input1
Audio output1
Remote (IR) input1
Serial interface typeRS-232
Serial ports quantity1
DC-in jackYes

Operational conditions

Operating relative humidity (H-H)0 - 80%
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C

Weight & dimensions

Width150.9 mm
Depth171.5 mm
Height30 mm
Weight640 g

Packaging data

Package width232 mm
Package depth500 mm
Package height283 mm
Package weight1.4 kg

Packaging content

AC adapter includedYes
Cables includedUSB
IR emitter includedYes
ManualYes
IR receiver includedYes

Technical details

Country of originTaiwan

Logistics data

Master (outer) case gross weight7.55 kg
Master (outer) case net weight5.87 kg
Products per master (outer) case5 pc(s)
