VE1843 AV extender AV transmitter & receiver Black
Model VE1843EAN 672792013072
33 specifications
- ConnectivityWired
- TypeAV transmitter & receiver
- Weight640 g
- ColourBlack
- Operating voltage12 V
- Operating relative humidity (H-H)0 - 80%
Overview
- Connectivity
- Wired
- Type
- AV transmitter & receiver
- Weight
- 640 g
- Colour
- Black
- Operating voltage
- 12 V
- Operating relative humidity (H-H)
- 0 - 80%
- Brand
- ATEN
- Category
- AV Extender
- Model
- VE1843
- Part numbers
- VE1843, VE1843-AT-G, VE1843-AT-U
- EAN / UPC
- 672792013072, 4710469341267
- Also known as
- ATEN VE1843 AV extender AV transmitter & receiver Black
Specifications
33 specifications in 6 groups
Features
| Specification | Value |
|---|---|
| Type | AV transmitter & receiver |
| Maximum resolution | 4096 x 2160 pixels |
| Cable types supported | Cat6a |
| Maximum transfer distance | 5 m |
| Maximum refresh rate | 60 Hz |
| 3D | Yes |
| Bandwidth | 18 Gbit/s |
| Firmware upgradeable | Yes |
| HDCP | Yes |
| HDCP version | 2.2 |
| Impedance | 100 Ω |
| Material | Metal |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| RJ-45 input ports | 1 |
| HDMI in | 1 |
| Number of HDMI outputs | 1 |
| USB ports quantity | 2 |
| USB connector type | USB Type-A, USB Type-B |
| Audio input | 1 |
| Audio output | 1 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Operating voltage | 12 V |
| Power consumption (typical) | 6.45 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 80% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 0 - 80% |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 171.5 mm |
| Depth | 150.9 mm |
| Height | 30 mm |
| Weight | 640 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
