True 4K HDMI/USB HDBT3.0-Lite
Model VE1833Part no. VE1833-AT-EEAN 4710469349829
46 specifications
- ConnectivityWired
- TypeAV transmitter & receiver
- Weight640 g
- ColourBlack
- Power source typeDC
- Operating relative humidity (H-H)0 - 80%
Overview
- Connectivity
- Wired
- Type
- AV transmitter & receiver
- Weight
- 640 g
- Colour
- Black
- Power source type
- DC
- Operating relative humidity (H-H)
- 0 - 80%
- Brand
- ATEN
- Category
- AV Extender
- Model
- VE1833
- Part numbers
- VE1833-AT-E, VE1833-AT-U, VE1833-AT-G
- EAN / UPC
- 4710469349829, 004710469829, 672792016707
- Also known as
- ATEN True 4K HDMI/USB HDBT3.0-Lite
Specifications
46 specifications in 8 groups
Features
| Specification | Value |
|---|---|
| Type | AV transmitter & receiver |
| Maximum resolution | 4096 x 2160 pixels |
| Maximum transfer distance | 5 m |
| High Dynamic Range (HDR) supported | Yes |
| Maximum refresh rate | 60 Hz |
| 3D | Yes |
| Bandwidth | 18 Gbit/s |
| Bandwidth | 600 MHz |
| Consumer Electronics Control (CEC) support | Yes |
| Firmware upgradeable | Yes |
| HDCP | Yes |
| HDCP version | 2.2/2.3 |
| Impedance | 100 Ω |
| LED indicators | Yes |
| Material | Metal |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Ethernet LAN | Yes |
| RJ-45 output ports | 1 |
| HDMI in | 1 |
| Number of HDMI outputs | 1 |
| USB ports quantity | 3 |
| USB connector type | USB Type-A, USB Type-B |
| 3.5 mm (1/8-inch) in | Yes |
| 3.5 mm (1/8-inch) out | Yes |
| Remote (IR) output | 1 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| Power consumption (TX) | 6.01 W |
| Power consumption (RX) | 7.09 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 80% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 146.9 mm |
| Depth | 169.4 mm |
| Height | 30 mm |
| Weight | 640 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 95 mm |
| Package depth | 265 mm |
| Package height | 220 mm |
| Package weight | 1.22 kg |
Technical details
| Specification | Value |
|---|---|
| Country of origin | Taiwan |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case width | 232 mm |
| Master (outer) case length | 500 mm |
| Master (outer) case height | 283 mm |
| Master (outer) case gross weight | 6.69 kg |
