ATEN VGA/Audio Over Cat5 Extender With MK

ATEN VGA/Audio Over Cat5 Extender With MK

Model VE157-AT-GEAN 4719264645693

52 specifications
  • ConnectivityWired
  • TypeAV transmitter & receiver
  • Weight445 g
  • ColourWhite
  • Operating voltage (transmitter)9 V
  • Operating relative humidity (H-H)0 - 80%
See all specifications

Overview

Connectivity
Wired
Type
AV transmitter & receiver
Weight
445 g
Colour
White
Operating voltage (transmitter)
9 V
Operating relative humidity (H-H)
0 - 80%
Brand
ATEN
Category
AV Extender
Model
VE157-AT-G
Part number
VE157-AT-G
EAN / UPC
4719264645693
Also known as
ATEN VGA/Audio Over Cat5 Extender With MK

Specifications

52 specifications in 8 groups

Features

TypeAV transmitter & receiver
Maximum resolution1920 x 1200 pixels
Cable types supportedCat5e, Cat6
Maximum transfer distance150 m
Audio systemstereo
Electrostatic Discharge (ESD) protectionYes
Electrostatic Discharge (ESD) protection15 kV
Bandwidth300 MHz
Impedance100 Ω
LED indicatorsYes
MaterialMetal
Plug and PlayYes
Resolution1920 x 1200 pixels
Supported graphics resolutions1280 x 1024 (SXGA), 1920 x 1200 (WUXGA)
Product colourWhite

Ports & interfaces

Connectivity technologyWired
Ethernet LANYes
RJ-45 input ports1
RJ-45 output ports1
VGA (D-Sub) input ports1
VGA (D-Sub) output ports1
Video in1
Video out1
Audio input1
Audio output1
VGA (D-Sub) ports quantity2

Power

Operating voltage (transmitter)9 V
Operating voltage (receiver)9 V
Power consumption (transmitter) (max)1.65 W
Power consumption (receiver) (max)0.95 W
External power adapterYes

Operational conditions

Operating relative humidity (H-H)0 - 80%
Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 60 °C

Weight & dimensions

Weight445 g
Receiver dimensions (WxDxH)44.4 x 68.6 x 42.8 mm
Receiver weight180 g
Transmitter dimensions (WxDxH)44.4 x 68.6 x 42.8 mm
Transmitter weight180 g

Packaging data

Quantity per pack2 pc(s)
Package width59 mm
Package depth239 mm
Package height160 mm
Package weight606 g

Packaging content

AC adapter includedYes
Quick start guideYes

Logistics data

Master (outer) case width250 mm
Master (outer) case length325 mm
Master (outer) case height175 mm
Master (outer) case gross weight3.45 kg
Master (outer) case net weight2.23 kg
Products per master (outer) case5 pc(s)
