True 4K HDMI Repeater with Audio Embedder and De-Embedder
Model VC882Part no. VC882-AT-GEAN 4710469341076
48 specifications
- ConnectivityWired
- TypeAV repeater
- Weight240 g
- ColourBlack
- External power adapterYes
- Operating relative humidity (H-H)0 - 80%
Overview
- Connectivity
- Wired
- Type
- AV repeater
- Weight
- 240 g
- Colour
- Black
- External power adapter
- Yes
- Operating relative humidity (H-H)
- 0 - 80%
- Brand
- ATEN
- Category
- AV Extender
- Model
- VC882
- Part numbers
- VC882-AT-G, VC882
- EAN / UPC
- 4710469341076, 672792012884
- Also known as
- ATEN True 4K HDMI Repeater with Audio Embedder and De-Embedder
Specifications
48 specifications in 9 groups
Features
| Specification | Value |
|---|---|
| Type | AV repeater |
| Maximum resolution | 4096 x 2160 pixels |
| Maximum transfer distance | 5 m |
| Maximum refresh rate | 60 Hz |
| Bandwidth | 18 Gbit/s |
| Bandwidth | 600 MHz |
| Firmware upgradeable | Yes |
| HDCP | Yes |
| HDCP version | 2.2 |
| Impedance | 100 Ω |
| LED indicators | Power |
| Material | Metal |
| Supported graphics resolutions | 4096 x 2160 |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| HDMI in | 1 |
| HDMI version | 2.0 |
| Number of HDMI outputs | 1 |
| USB ports quantity | 1 |
| USB connector type | Micro-USB |
| Digital audio coaxial in | 1 |
| Digital audio coaxial out | 1 |
| Audio input | 3-pin terminal |
| Audio output | 3-pin terminal |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| External power adapter | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 80% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 82.2 mm |
| Depth | 122.2 mm |
| Height | 25 mm |
| Weight | 240 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 59 mm |
| Package depth | 239 mm |
| Package height | 160 mm |
| Package weight | 970 g |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Manual | Yes |
Technical details
| Specification | Value |
|---|---|
| Country of origin | Taiwan |
| Package volume | 2265.35 cm³ |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case width | 250 mm |
| Master (outer) case length | 325 mm |
| Master (outer) case height | 175 mm |
| Master (outer) case gross weight | 4.62 kg |
| Master (outer) case net weight | 3.92 kg |
| Master (outer) case volume | 14158.42 cm³ |
| Products per master (outer) case | 5 pc(s) |
