Zyxel WAH7706 v2

Zyxel WAH7706 v2

Model WAH7706 v2Part no. WAH7706-EU01V2FEAN 4059313121427

56 specifications

Battery2800 mAh
SpeedWi-Fi 5 (802.11ac)
TypePortable router
Weight115 g
ColourBlack
SIM card slotYes

See all specifications

Overview

Battery: 2800 mAh
Speed: Wi-Fi 5 (802.11ac)
Type: Portable router
Weight: 115 g
Colour: Black
SIM card slot: Yes

Brand: Zyxel
Category: Wireless Router
Model: WAH7706 v2
Part number: WAH7706-EU01V2F
EAN / UPC: 4059313121427, 4718937590964
Also known as: Zyxel WAH7706 v2 wireless router Dual-band (2.4 GHz / 5 GHz) 4G Black

Specifications

56 specifications in 18 groups

WAN connection

Specification	Value
SIM card slot	Yes

Wireless LAN features

Specification	Value
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	300 Mbit/s
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)

Network

Specification	Value
Ethernet LAN	No
Ethernet LAN interface type	Not available
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

Mobile network

Specification	Value
Mobile network generation	4G
3G	Yes
4G	Yes
2G standards	Edge, GPRS, GSM
3G standards	DC-HSDPA, DC-HSPA+, HSPA+, HSUPA, UMTS
4G standard	LTE
Short Message Service (SMS)	Yes

Ports & interfaces

Specification	Value
USB port	Yes
RJ-11 ports quantity	1
Memory card slot(s)	Yes
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB

Management features

Specification	Value
Web-based management	Yes
Reset button	Yes

Security

Specification	Value
Security algorithms	EAP-AKA, WPA, WPA2, WPA2-PSK, WPS
Authentication method	VPN
Firewall	Yes
Network address translation (NAT)	Yes

Protocols

Specification	Value
DHCP server	Yes

Design

Specification	Value
Product type	Portable router
Product colour	Black
LED indicators	Power, WLAN
On/off switch	Yes

Battery

Specification	Value
Battery technology	Lithium Polymer (LiPo)
Battery capacity	2800 mAh

Packaging content

Specification	Value
Quick start guide	Yes

Antenna

Specification	Value
Antenna design	Internal
Antennas quantity	2

Power

Specification	Value
Power source type	Battery
Battery voltage	3.8 V
Battery life (max)	10 h

Operational conditions

Specification	Value
Operating relative humidity (H-H)	5 - 95%
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95%
Storage temperature (T-T)	-20 - 60 °C

System requirements

Specification	Value
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 H
Linux operating systems supported	Yes
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.9 Mavericks
Mac compatibility	Yes

Weight & dimensions

Specification	Value
Depth	65.5 mm
Height	14.5 mm
Weight	115 g
Width	111 mm

Packaging data

Specification	Value
Package width	150 mm
Package depth	106 mm
Package height	42 mm
Package weight	215 g

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
