SIL iSITE Switch
Model SIL iSITE SwitchEAN 5060693982491
94 specifications
- Memory128 MB
- SpeedWi-Fi 4 (802.11n)
- TypePortable router
- Weight485 g
- ColourBlack
- Ethernet WANYes
Overview
- Memory
- 128 MB
- Speed
- Wi-Fi 4 (802.11n)
- Type
- Portable router
- Weight
- 485 g
- Colour
- Black
- Ethernet WAN
- Yes
- Brand
- SilverNet
- Category
- Wireless Router
- Model
- SIL iSITE Switch
- Part number
- SIL iSITE Switch
- EAN / UPC
- 5060693982491
- Also known as
- SilverNet SIL iSITE Switch
Specifications
94 specifications in 18 groups
WAN connection
| Specification | Value |
|---|---|
| Ethernet WAN | Yes |
| DSL WAN | No |
| SIM card slot | Yes |
| 3G/4G USB modem compatibility | No |
| WAN connection type | RJ-45 |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Single-band (2.4 GHz) |
| Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (max) | 65 Mbit/s |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (first band) | 11 Mbit/s |
| WLAN data transfer rate (second band) | 54 Mbit/s |
| WLAN data transfer rate (third band) | 65 Mbit/s |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Fast Ethernet |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Cabling technology | 10/100Base-T(X) |
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at |
| Auto-sensing | Yes |
| Full duplex | Yes |
| Flow control support | Yes |
| Multicast support | Yes |
| Port forwarding | Yes |
| Load balancing system | Yes |
| Automatic channel selection | Yes |
| Dynamic DNS (DDNS) | Yes |
| Policy-based routing | Yes |
| Static route | Yes |
| VPN Passthrough | Yes |
Mobile network
| Specification | Value |
|---|---|
| Mobile network generation | 4G |
| Dual SIM support | Yes |
| SIM card type | MicroSIM |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 4 |
| USB port | No |
| Terminal block port | Yes |
| RS-485 ports | 1 |
| RS-232 ports | 1 |
Management features
| Specification | Value |
|---|---|
| Web-based management | Yes |
| Bandwidth control | Yes |
| Quality of Service (QoS) support | Yes |
| Reset button | Yes |
Security
| Specification | Value |
|---|---|
| Security algorithms | HTTPS, SNMP, SNMPv2, SNMPv3, WPA-AES, WPA-PSK, WPA-TKIP, WPA2, WPA2-AES, WPA2-PSK, WPA2-TKIP |
| Access Control List (ACL) | Yes |
| DDoS protection | Yes |
| DoS attack prevention | Yes |
| Filtering | Yes |
| MAC address filtering | Yes |
| IP address filtering | Yes |
| System event log | Yes |
| DMZ support | Yes |
Protocols
| Specification | Value |
|---|---|
| DHCP client | Yes |
| DHCP server | Yes |
| Routing protocols | OSPF, RIP-1, RIP-2, VRRP |
| Management protocols | Web, CLI, SMS, On-demand dial up, SNMP v1/v2/v3 |
| Supported network protocols | IPv4/IPv6, PPP, PPPoE, SNMP v1/v2c/v3, TCP, UDP, DHCP, DDNS, HTTP, HTTPS, DNS, ARP, QOS, SNTP, Telnet, VLAN, SSH |
Design
| Specification | Value |
|---|---|
| Product type | Portable router |
| Product colour | Black |
| Housing material | Aluminium |
| Wall mountable | Yes |
| International Protection (IP) code | IP40 |
| LED indicators | Activity, LAN, Power, System, VPN, WLAN |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Antenna included | Yes |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, FCC, RCM RoHS IEC 61000-4-2 Level 3 IEC 61000-4-3 Level 2 IEC 61000-4-4 Level 3 IEC 61000-4-5 Level 3 IEC 61000-4-6 Level 3 IEC 61000-4-8 Level 4 IEC 61000-4-11 Level 3 EN 301 489-1/17/19/52, EN 301 511, EN 301 908-1/2/13, EN 303 413, EN300 328 EN62368-1 |
Antenna
| Specification | Value |
|---|---|
| Antenna design | External |
| Antenna connector type | RJ-SMA |
| Antennas quantity | 4 |
Features
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor architecture | ARM Cortex A7 |
| Processor frequency | 528 MHz |
| Internal memory | 128 MB |
| Flash memory | 128 MB |
| Watch Dog function | Yes |
| Firmware upgradeable | Yes |
| Electromagnetic compatibility | EN 55032, EN 55035 |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| Power consumption (typical) | 3.9 W |
| Power over Ethernet (PoE) | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | -40 - 85 °C |
| Isolation | 1.5 kV |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 103 mm |
| Height | 135 mm |
| Weight | 485 g |
| Width | 45 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 195 mm |
| Package depth | 340 mm |
| Package height | 55 mm |
| Package weight | 1.32 kg |
| Package type | Box |
| Number of products included | 1 pc(s) |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | United Kingdom |
| UK Trade Tariff code | 85176200 |
| Warranty period | 2 year(s) |
